Airtac ATE Single Acting Guided Compact Cylinder ATE100X10SB
$117.68
Regular price
$125.18
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ATE100X10SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 21287 standard for enhanced cross-brand installation compatibility;
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
Installation note:
Maintain ≥5mm clearance around cylinder body for heat dissipation.
For vertical mounting, use auxiliary guide mechanisms when handling
eccentric loads exceeding 20% of maximum capacity. Lubricate through
air supply (oil-fog lubrication) at 1 drop/minute/1m³ flow rate.
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE100X10SB Single-Acting Compact Cylinder Specifications
- Model: ATE100X10SB
- Type: Single-acting spring return (introduction type)
- Bore size: 100mm
- Stroke: 10mm
- Operating pressure: 0.15–0.8 MPa
- Port size: PT1/4 (G1/8 optional)
- Cushioning: Rubber buffer (adjustable)
- Material: Aluminum alloy body, NBR seals
- Weight: 2.8kg (without accessories)
- Dimensions: 150mm(L) × 118mm(W) × 118mm(H)
- Operating temperature: -20℃ to 80℃
- Piston speed: 50–800mm/s
- Protection rating: IP40 (standard)
- Mounting options: Basic type (no built-in mounts)
Ultra-compact cylinder with space-saving design (30% shorter than standard cylinders), featuring enhanced lateral load resistance through integrated guide mechanism. The hexagonal body structure prevents rotation during operation. Requires filtered air (40μm+) with ISO VG32 lubricator oil for optimal performance.
Typical Applications:
- High-density automation cells in electronics assembly
- Clamping fixtures for CNC machine tooling
- Vertical lifting mechanisms in packaging lines
- Medical sterilization equipment door actuators
- Food processing conveyor gate controls
Installation note:
Maintain ≥5mm clearance around cylinder body for heat dissipation.
For vertical mounting, use auxiliary guide mechanisms when handling
eccentric loads exceeding 20% of maximum capacity. Lubricate through
air supply (oil-fog lubrication) at 1 drop/minute/1m³ flow rate.
| Property | Property Value |
|---|---|
| sku | ATE100X10SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <10mm> |
