This model is discontinued
AirTAC has phased out the MAL series. The drop-in replacement is ATE12X5 — same bore, stroke, output force, port and mounting, so it fits the same application. Simply order the ATE12X5 in place of this model. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ATP Single Acting Port Compact Cylinder ATP12X5
The AirTAC Airtac ATP Single Acting Port Compact Cylinder ATP12X5 is a single acting, pull (spring return) DIN-standard tight/compact air cylinder with a Ø12mm bore and 5mm stroke, M5×0.8 air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ATE12X5 (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ12 mm
- Stroke5 mm
- Port sizeM5×0.8
- Acting typeSingle acting, pull (spring return)
- Rod threadM3×0.5
- StatusDiscontinued → ATE12X5
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ATP Single Acting Port Compact Cylinder ATP12X5
A single acting compact pull cylinder, the ATP12X5 uses an internal spring to extend the rod and compressed air to retract it, so the 12 mm bore delivers a net pull of 25.9 N at 0.5 MPa (42.9 N at 0.7 MPa) after the spring is subtracted. It needs at least 0.2 MPa of air to overcome the spring, runs on 40 um filtered air at 0.2-1.0 MPa (28-145 psi), and moves at 50-500 mm/s. This model is discontinued; the current-production replacement is the ATE12X5 in the same bore, stroke and force class.
The short ISO 21287-class body saves roughly 50% of the mounting length of an ISO 15552 profile cylinder, which is why it suits micro jigs and sensor stations where every millimetre counts. The hard-anodized aluminium body carries an S45C hard-chrome rod with a female M3x0.5 thread, and fixed TPU bumpers sit at both ends. Plan on about 15 N of usable pull at 0.5 MPa, which lifts roughly 1.5 kg vertically with a 2:1 margin. No magnet is fitted on this code; order the optional -S version to enable CMSE / DMSE switches.
Airtac ATP Single Acting Port Compact Cylinder ATP12X5 Technical Specifications
| Model | Airtac ATP Single Acting Port Compact Cylinder ATP12X5 |
|---|---|
| Series | ATP DIN compact cylinder (discontinued) |
| Replacement | ATE12X5 |
| Bore size | Ø12 mm |
| Stroke | 5 mm |
| Acting type | Single acting, pull (spring return) |
| Port size | M5×0.8 |
| Rod thread | M3×0.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 10 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ATE12X5 (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø12mm)
| Pressure | Pull force (spring return) |
|---|---|
| 0.5 MPa | 25.9 N |
| 0.7 MPa | 42.9 N |
Single-acting pull: the spring extends the rod; air retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac ATP Single Acting Port Compact Cylinder ATP12X5
| ATP | DIN compact cylinder (single-acting pull, spring-return, discontinued). |
|---|---|
| 12 | Bore size in mm. |
| ×5 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (adjustable stroke).
Where the Airtac ATP Single Acting Port Compact Cylinder ATP12X5 Is Used
Micro part ejection from vision-inspection nests
The spring-extended rod holds a tiny ejector pin forward at rest; 25.9 N of air pull at 0.5 MPa retracts it 5 mm so the camera gets a clear view of the part.
Spring-forward gate on a small rotary indexing table
On air loss the spring returns the gate to its extended home position, a fail-safe posture for clearing jammed components in a compact 5 mm travel window.
Sample probe retraction in a laboratory dispenser
The 1.5 kg-class vertical pull (about 15 N usable) is enough to withdraw a light sampling probe, and the short body fits inside the instrument housing.
Replacing the Airtac ATP Single Acting Port Compact Cylinder ATP12X5 with the ATE12X5
At 25.9 N of net pull at 0.5 MPa this 12 mm bore is the smallest in the family; step up to the 16 mm bore (53.3 N) if your mechanism needs roughly twice the retraction force, or downsize from a 16 if 25.9 N already covers it. The 5 mm stroke is well inside the standard range for this bore, so no made-to-order stroke is needed. Match FA/FB flange, LB foot or CA/CB clevis brackets to your fixture, add the -S code only if you need CMSE / DMSE position switches, and confirm the ATE12X5 ISO 21287 mounting dimensions before swapping from this discontinued unit.
Replacement checklist
- ✓ Current-production ACE → ATE12X5
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ATP Single Acting Port Compact Cylinder ATP12X5 FAQ
Net of the return spring, the 12 mm bore pulls 25.9 N at 0.5 MPa and 42.9 N at 0.7 MPa; 0.2 MPa minimum air is needed to beat the spring. Operating range is 0.2-1.0 MPa (28-145 psi), proof 1.5 MPa (215 psi), temperature -20 to +70 C, speed 50-500 mm/s, stroke 5 mm with a 6 mm rod on a female M3x0.5 thread and an M5x0.8 PT port. The model is discontinued; the ATE12X5 is the current drop-in.
The spring pushes the rod to its extended home position and holds it there, so the cylinder fails to extended; it does not hold a mid-stroke position and the fixed TPU bumpers only decelerate the rod at each end of travel. If you need position sensing, order the optional -S magnet version, which accepts CMSE / DMSE switches - this base code carries no magnet.
Request a Quote for the ATE12X5
Send us the quantity and destination. We confirm price, stock and lead time on the ATE12X5 replacement — usually within 7-8 hours.
