Airtac ATE Single Acting Guided Compact Cylinder ATE12X5
$27.41
Regular price
$34.91
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ATE12X5
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 21287 standard for enhanced cross-brand installation compatibility;
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
Installation guidance:
Lubricate with ISO VG32 turbine oil before operation.
For vertical mounting, use spring-side port as exhaust.
Maintain 0.3mm minimum clearance between rod end and workpiece.
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE12X5 Single-Acting Compact Round Cylinder Specifications
- Model: ATE12X5 (X=Stroke Code: 5=50mm)
- Type: Single-acting spring return (non-rotating rod)
- Bore size: Φ12mm
- Stroke: 50mm (Standard) | Customizable up to 300mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable elastic cushion
- Port size: M5×0.8 (1/8" NPT optional)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Seal material: NBR (Nitrile) standard | FKM optional
- Weight: 0.28 kg (with bracket)
- Dimensions:
- Body diameter: Φ32mm
- Total length: 130mm (50mm stroke)
- Mounting spacing: 25mm (front/rear)
- Rod thread: M6×1.0
Ultra-compact cylinder featuring anti-rotation mechanism and ISO 6432 compliance. Precision honed aluminum tube with hard anodized finish ensures wear resistance. Integrated mounting slots allow direct attachment without separate brackets. Optional magnetic piston version (ATE12X5-M) available for position sensing.
Ideal Applications:
- PCB handling robots in electronics manufacturing
- Pharmaceutical blister packaging machines
- Automated test equipment actuation
- Cleanroom material transfer systems
- Precision clamping fixtures
Installation guidance:
Lubricate with ISO VG32 turbine oil before operation.
For vertical mounting, use spring-side port as exhaust.
Maintain 0.3mm minimum clearance between rod end and workpiece.
⚠️ Critical parameters:
Max side load: 4.9N | Max moment: 0.7N·m |
Lubrication interval: 2,000km stroke travel
| Property | Property Value |
|---|---|
| sku | ATE12X5 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
