Airtac GAC F.R.L. Unit GAC20006AL
The AirTAC Airtac GAC F.R.L. Unit GAC20006AL is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeCircular, MPa / psi
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006AL
Delivering cleaned, regulated and lubricated air for single actuators, the AirTAC GAC20006AL is a three-unit F.R.L. combination pre-plumbed on a single L-shape bracket. This compact 750 g assembly features a 1/8in port, a 40 um filter element, and a lower-pressure type regulator operating at 0.15-0.4 MPa (20-58 psi). The automatic drain clears condensate from the 25 cc bowl without an operator, making it well suited to unattended or wet lines.
Air passes through the filter, then the regulator, and finally the lubricator, ensuring oil mist is added downstream so the regulator seat never fouls. A circular gauge is fitted, reading MPa/psi for the default PT thread, allowing operators to monitor the set pressure directly. If your machine requires oil-free air downstream, omit the lubricator and choose a separate filter-regulator instead.
Airtac GAC F.R.L. Unit GAC20006AL Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006AL |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. The fitted circular gauge reads in MPa / psi, set by the PT thread code.
Model Code: Airtac GAC F.R.L. Unit GAC20006AL
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| (blank) | Circular pressure gauge fitted. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006AL Is Used
Small Pneumatic Jigs
Feeds clean, lubricated air at low pressure to delicate single-actuator jigs and small clamping fixtures in electronics assembly.
Benchtop Tooling
Conditions air for light benchtop grinders or micro-drills where a 1/8in port and a 0.4 MPa ceiling match the tool requirements.
Lab Automation
Prepares supply for laboratory pick-and-place arms, relying on the automatic drain to clear condensate during unattended overnight cycles.
Is the Airtac GAC F.R.L. Unit GAC20006AL the Right Air-Prep Unit?
This GAC200 body uses a 1/8in port and offers a flow envelope plotted to 1750 L/min at 0.7 MPa inlet, which is roughly 58% of the GAC300's 3000 L/min curve, placing it firmly in the compact class for light-duty tasks. The lower-pressure type L tops out at 0.4 MPa, so if the machine may ever need more, this is the wrong part. The automatic drain is decisive for wet lines, while the standard 40 um element balances protection with service frequency. Spares are available as GAF200-06, GAR200-06 and GAL200-06. Note that 0.4 MPa is about 44% of the Standard type's 0.9 MPa ceiling, quantifying what the buyer gives up when choosing L.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006AL FAQ
This model operates at 0.15-0.4 MPa (20-58 psi) with a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). It has a temperature range of -5 to 70 C, a 25 cc drain bowl, a 36 cc oil bowl, and weighs 750 g. The recommended lubricant is ISO VG 32.
The automatic drain clears condensate from the 25 cc PC bowl without an operator, which is especially useful for unattended or wet lines. It eliminates the need for manual intervention compared to the semi-auto and manual drain pair found on blank-drain models.
