Airtac GAC F.R.L. Unit GAC20006SNK
The AirTAC Airtac GAC F.R.L. Unit GAC20006SNK is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainsemi-auto + manual
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006SNK
Delivering cleaned, regulated and lubricated air for single actuators, this AirTAC GAC20006SNK is a three-unit F.R.L. combination pre-plumbed on a single L-shape bracket. The 1/8in port feeds a standard pressure range of 0.15-0.9 MPa (20-130 psi) through a 40 um element. Because the lubricator sits downstream of the regulator, the oil mist never fouls the regulator seat.
Weighing 750 g, this compact assembly carries a 25 cc condensate bowl and a 36 cc oil reservoir. This model ships without a gauge, though a 1/8in gauge connection is provided if you need to add instrumentation later. The reverse-flow (reflux) valve is fitted, which the catalogue shows as a separate pneumatic symbol with details on its own page.
Airtac GAC F.R.L. Unit GAC20006SNK Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006SNK |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006SNK
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006SNK Is Used
Small Pneumatic Jigs
Feeds a single small-bore cylinder on a benchtop jig where space is tight and a 1/8in port is sufficient.
Pick-and-Place Heads
Conditions air for miniature grippers and vacuum generators that require steady pressure and a fine oil mist.
Laboratory Air Tools
Prepares supply for low-consumption lab-scale air motors and light-duty screwdrivers operating intermittently.
Is the Airtac GAC F.R.L. Unit GAC20006SNK the Right Air-Prep Unit?
Choose this GAC200 body for light-duty tasks, stepping up to the GAC300 if you need a larger 60 cc drain bowl or a flow envelope plotted to 3000 L/min at 0.7 MPa inlet instead of the 1750 L/min curve on this unit. The PC bowl, standard 0.15-0.9 MPa type, and 40 um element suit general plant air, while the semi-auto and manual drain pair gives you two ways to clear condensate. If the downstream line must stay oil-free, omit the lubricator and choose a filter-regulator instead. Replacement parts share the same body-port suffix: GAF200-06, GAR200-06 and GAL200-06. Since the max supply is 1.0 MPa and the standard type regulates to 0.9 MPa, there is only about 0.1 MPa of headroom above the top setting, so plan a supply near 1.0 MPa if you truly need 0.9 MPa out.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006SNK FAQ
This standard type unit regulates from 0.15-0.9 MPa (20-130 psi) with a maximum pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). It operates from -5 to 70 C, weighs 750 g, holds 25 cc of condensate and 36 cc of oil, and uses ISO VG 32 lubricant.
The N in the ordering code means no gauge is supplied, so the set pressure cannot be read without adding one. The body features a 1/8in gauge connection, allowing you to install a compatible PT-thread gauge reading in MPa/psi to monitor downstream pressure.
