Airtac GAC F.R.L. Unit GAC20006SNW
The AirTAC Airtac GAC F.R.L. Unit GAC20006SNW is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainsemi-auto + manual
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006SNW
Delivering cleaned, regulated and lubricated air for a single actuator, this AirTAC F.R.L. combination integrates a filter, regulator and lubricator on one L-shape bracket. The 1/8in port pairs with a 5 um element to trap fine particles before they reach precision valves, while the standard type regulates pressure across 0.15-0.9 MPa (20-130 psi).
The build sequence routes air through the filter first and the lubricator last, ensuring oil mist is added downstream so the regulator seat never fouls. Because the N follows the port, no gauge is supplied out of the box, though a 1/8in gauge connection is provided if you need to add instrumentation later. The 25 cc condensate bowl relies on a semi-auto and manual drain pair, demanding operator attendance in wet conditions.
Airtac GAC F.R.L. Unit GAC20006SNW Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006SNW |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006SNW
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006SNW Is Used
Micro-Pneumatic Jigs
Feeds clean, lubricated air at a stable pressure to small precision pick-and-place heads using delicate grippers.
Lab Automation
Prepares supply air for compact analytical instruments where a 5 um element prevents particulate fouling of tiny orifices.
Single-Actuator Stations
Conditions air for individual small-bore cylinders on test fixtures, ensuring consistent cycling via the lubricator.
Is the Airtac GAC F.R.L. Unit GAC20006SNW the Right Air-Prep Unit?
Choose this 750 g unit for light-duty jigs where space is tight and a 5 um element is required to protect sensitive pneumatics. The PC bowl suits general industrial environments, and the PT thread sets the default MPa/psi scale if a gauge is added to the 1/8in connection. If the machine requires oil-free air downstream, omit the lubricator and select a filter-regulator instead. Should the element clog or bowl crack, order the GAF200-06, GAR200-06 and GAL200-06 spares rather than replacing the whole assembly. Stepping up to the GAC300 roughly doubles the flow envelope from 1750 to 3000 L/min at 0.7 MPa inlet, but keep in mind the standard type tops out at 0.9 MPa against a 1.0 MPa maximum, leaving only 0.1 MPa of regulation headroom.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006SNW FAQ
This model operates at 0.15-0.9 MPa (20-130 psi) with a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). It has a 5 um element, a 25 cc drain bowl, a 36 cc oil bowl, and weighs 750 g. The temperature range is -5 to 70 C, and the recommended lubricant is ISO VG 32.
The N in the model code indicates that no circular gauge is supplied. The unit features a 1/8in gauge connection, allowing you to install a separate pressure gauge reading in MPa/psi to match the default PT thread scale.
