Airtac SE32 Standard Cylinder SE32X300
The AirTAC Airtac SE32 Standard Cylinder SE32X300 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 300mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ32 mm
- Stroke300 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
About the Airtac SE32 Standard Cylinder SE32X300
The AirTAC SE32X300 is a double-acting, single-rod ISO 15552 profile cylinder engineered for compact automation. It delivers a 402 N push force at 0.5 MPa across a 300 mm stroke, utilizing a 12 mm hard-chrome plated rod and an M10x1.25 thread. The square extruded aluminum barrel omits external tie rods, yielding a flush, corrosion-resistant body that mounts cleanly in tight machine envelopes.
Field-adjustable pneumatic cushioning at both ends allows technicians to tune end-of-stroke deceleration via a set screw, softening hard impacts when cycling at speeds up to 800 mm/s. This specific SKU is configured without a built-in magnet, meaning it is not wired for CMSE or DMSE position sensing out of the box.
Airtac SE32 Standard Cylinder SE32X300 Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32X300 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 300 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32X300
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×300 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32X300 Is Used
PCB Depaneling Router
Routes assembled circuit boards on a 300 mm slide, using the 402 N push force to drive the cutting spindle precisely through panel breakouts without stressing adjacent components.
Lab Sample Dispenser
Actuates a 300 mm travel pipetting head, moving fluid vials between stations where the clean, tie-rod-free extruded barrel prevents dust accumulation in sterile environments.
Small Part Ejector
Kicks stamped micro-parts out of a progressive die, relying on adjustable end cushions to softly stop the 12 mm rod at high cycling speeds without shock-loading the die plate.
Is the Airtac SE32 Standard Cylinder SE32X300 the Right Cylinder?
Selecting this 32 mm bore yields 402 N of push force at 0.5 MPa. If your application requires less energy, the adjacent smaller standard bore is unavailable in this series, making 32 mm the baseline; conversely, stepping up to the 40 mm bore provides 628 N of push. Because this cylinder lacks a rod lock, it cannot hold a load dynamically if air pressure drops—the piston will drift, so a BSE variant or external check valve is required for fail-safe positioning. With a 300 mm stroke, the unsupported 12 mm rod is prone to bending under side loads, so an external guide bearing is strongly recommended to prevent premature seal wear.
For ISO 15552 retrofits, match the 32 mm bore, 300 mm stroke, PT1/8 port, and basic mounting interface. You can reuse existing foot or flange hardware since the standardized footprint ensures drop-in compatibility.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32X300 FAQ
The SE32X300 provides a push force of 402 N and a pull force of 345 N at 0.5 MPa. At 0.7 MPa, the push force is 563 N. The maximum push force is 82 kgf when operated at the 1.0 MPa pressure limit.
Yes, the SE32X300 shares the exact ISO 15552 / VDMA 24562 mounting interface and dimensions, allowing it to function as a drop-in replacement for other brands' ISO 15552 profile cylinders. Note that this specific SKU lacks the -S magnet, so it cannot host CMSE or DMSE sensors without modification.
