Airtac SE32 Standard Cylinder SE32X200
The AirTAC Airtac SE32 Standard Cylinder SE32X200 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 200mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ32 mm
- Stroke200 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
About the Airtac SE32 Standard Cylinder SE32X200
The AirTAC SE32X200 is a double-acting single-rod ISO 15552 profile cylinder engineered for compact actuation, delivering a 402 N push at 0.5 MPa. Its square extruded aluminum barrel eliminates external tie rods, yielding a flush, corrosion-resistant housing that mounts cleanly in tight machine envelopes.
This 32 mm bore unit features a 12 mm rod and a 27 mm adjustable pneumatic cushion at both ends to soften end-of-stroke impacts. Because this specific SKU lacks the S magnet code, it does not support direct CMSE or DMSE position sensing without modification.
Airtac SE32 Standard Cylinder SE32X200 Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32X200 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 200 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32X200
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32X200 Is Used
PCB Depaneling Router
Provides the precise 402 N clamping force needed to secure circuit boards during automated routing without flexing the 200 mm stroke.
Package Sorting Diverter
Actuates lightweight cardboard cartons on a packaging line where the compact tie-rod-free profile prevents dust accumulation.
Lab Sample Dispenser
Drives a 200 mm linear stroke to move fluid vials into a testing carousel, relying on adjustable cushions to prevent sudden jolts.
Is the Airtac SE32 Standard Cylinder SE32X200 the Right Cylinder?
Selecting the SE32X200 is ideal when you need 402 N of push force at 0.5 MPa within a standardized ISO 15552 footprint. If your application requires less force, the adjacent 32 mm bore is the smallest standard size; stepping up to the 40 mm bore yields 628 N of push. This model utilizes a PT1/8 port and a basic mounting style.
With a 200 mm stroke, the 12 mm rod carries moderate side-load capacity, but any unsupported heavy load should still use an external guide. Note that the adjustable air cushion only decelerates the piston near stroke end and will not hold a load if air pressure is lost. For position holding, consider a BSE rod lock variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32X200 FAQ
The SE32X200 delivers a push force of 402 N and a pull force of 345 N at 0.5 MPa. At 0.7 MPa, the push force is 563 N, with a maximum push capacity of 82 kgf at 1.0 MPa. This 32 mm bore cylinder uses a PT1/8 port.
Yes, the SE32X200 shares the exact ISO 15552 / VDMA 24562 mounting interface, allowing it to serve as a drop-in replacement for other ISO 15552 profile cylinders. It uses standard mounting accessories and features an extruded aluminum body without external tie rods.
