Airtac SE32 Standard Cylinder SE32X50
The AirTAC Airtac SE32 Standard Cylinder SE32X50 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 50mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ32 mm
- Stroke50 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
About the Airtac SE32 Standard Cylinder SE32X50
The AirTAC SE32X50 is a double-acting single-rod ISO 15552 profile cylinder engineered for compact automation. It delivers a 402 N push at 0.5 MPa, utilizing a 12 mm rod and a PT1/8 port to achieve smooth motion across its 50 mm stroke. The extruded aluminum barrel omits external tie rods, yielding a flush, corrosion-resistant body that mounts cleanly in tight machinery.
Because this specific SKU lacks the -S magnet code, it operates without position sensing out of the box. You can still fine-tune the end-of-stroke deceleration using the field-adjustable air cushion at both ends, which turns a harsh impact into a soft stop without adding fixed bumpers.
Airtac SE32 Standard Cylinder SE32X50 Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32X50 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 50 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32X50
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×50 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32X50 Is Used
PCB Routing Head
Drives a small routing head across 50 mm of travel in an electronics PCB depaneling machine, applying precise 402 N force without bulky external frame rails.
Pouch Dispenser
Pushes packaging film into a sealing jaw on a vertical form-fill-seal unit, using the flush extruded barrel to fit neatly within the narrow stainless steel frame.
Lab Sample Ejector
Ejects processed vial trays from a centrifuge carousel, relying on the adjustable pneumatic cushion to decelerate the 12 mm rod gently before the end of stroke.
Is the Airtac SE32 Standard Cylinder SE32X50 the Right Cylinder?
This 32 mm bore is the entry point for the AirTAC SE line, generating 402 N of push at 0.5 MPa. If your assembly requires less force, stepping down is not an option within this series, but if you need more power, the next size up is the 40 mm bore which provides 628 N of push at 0.5 MPa. For replacing existing hardware, the standardized ISO 15552 mounting interface ensures a drop-in fit for any matching 32 mm bore and 50 mm stroke profile cylinder using standard brackets.
Keep in mind that a plain SE cylinder will drift if air pressure is lost or the valve centers; it cannot hold a load vertically without live pressure. If your cycle demands positive holding, you would need to step over to the BSE rod-lock variant or utilize an external pilot-operated check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32X50 FAQ
The SE32X50 generates 402 N of push force and 345 N of pull force at 0.5 MPa. At 0.7 MPa, the push force increases to 563 N, and the maximum push force is 82 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
Yes, the SE32X50 is a true ISO 15552 profile cylinder, making it dimensionally interchangeable with other ISO 15552 cylinders of the same bore and stroke. You can reuse existing mounting accessories and port connections, noting that this unit uses a PT1/8 port and lacks a position-sensing magnet.
