Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-50SLB
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Piston seal utilizes dual Y-type bidirectional sealing structure with compensation function, offering long service life and low dynamic friction;
3. Cross-shaped tube design with triple tie-rod structure ensures excellent corrosion resistance;
4. Smooth adjustable cushioning mechanism with stable operation;
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTC | Series: SIJ32
AirTAC SIJ32X100-50SLB Dual-Axis Adjustable Cylinder Specifications
- Model: SIJ32X100-50SLB
- Type: Dual-axis adjustable profile cylinder (Twin rod)
- Bore size: 32mm
- Stroke: 100mm (±0.5mm adjustment range)
- Operating pressure: 0.05–0.9 MPa
- Piston rod diameter: 12mm (both rods)
- Mounting type: LB (axial foot + front flange)
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (G1/8 equivalent flow)
- Ambient temperature: -10℃ to 80℃
- Material: Aluminum alloy barrel, CR12MoV piston rod
- Seal type: NBR seals with wear-resistant ring
- Weight: 2.45kg ±2%
- Dimensions:
- Total length: 196mm (at mid-stroke)
- Body width: 50mm
- Height with mounting: 78mm
- Center-to-center rod spacing: 32mm
High-precision twin-rod cylinder featuring micrometer-style stroke adjustment (±0.5mm) via locknut mechanism. Anti-rotation design maintains parallel rod alignment under heavy side loads. Pre-lubricated for maintenance-free operation up to 3,000km travel life. Includes magnetic piston for sensor compatibility.
- Precision fixture positioning in CNC machining centers
- Vertical lifting mechanisms in semiconductor handling
- Parallel gripper drives in robotic assembly systems
- Web tension control in printing/packaging lines
- Automated inspection equipment alignment
Installation tip:
Use precision level during mounting (max 0.1mm/m alignment tolerance). For vertical installations,
add external guide mechanisms when handling loads exceeding 15kg. Lubricate rod ends weekly in
high-cycle applications (>500 cycles/min).
| Property | Property Value |
|---|---|
| sku | SIJ32X100-50SLB |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
