Airtac ASQ Series Single Acting Slim Cylinder ASQ16X10H
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ16X10H Single-Acting Compact Cylinder Specifications
- Model: ASQ16X10H
- Type: Single-acting spring return (piston type)
- Bore size: 16mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Spring force: 4.1N (at 0.5 MPa)
- Port thread: M5×0.8 (dual ports)
- Cushioning: Rubber buffer (both ends)
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.22kg ±3%
- Dimensions (L×W×H): 46mm × 25mm × 25mm (excluding rod)
- Mounting: Double stud (ISO 6432 standard)
- Protection rating: IP40 (standard seals)
Ultra-slim profile cylinder with 16mm bore designed for space-constrained automation systems. Features corrosion-resistant construction and dual air ports for flexible piping. The built-in spring provides reliable return motion without external power. Requires 40μm filtered dry air and ISO VG32 hydraulic oil lubrication (optional).
- PCB handling robots in electronics assembly
- Clamping mechanisms in CNC jig systems
- Valve actuation in medical equipment
- Paper feed mechanisms in printers/copiers
- Sorting gates in packaging lines
Installation tips:
Maximum allowable lateral load 5N. Maintain 0.5mm minimum alignment tolerance between rod and load.
Lubricate through air port (1-2 drops of ISO VG32 oil per 1,000 cycles recommended).
| Property | Property Value |
|---|---|
| sku | ASQ16X10H |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
