AirTAC PA Nylon Tubing PA12040025200MBU Specifications

• Model: PA12040025200MBU
• Material: Nylon 12 (PA12) with UV stabilizers
• Outer Diameter (OD): 12.0 mm ±0.1 mm
• Inner Diameter (ID): 4.0 mm ±0.05 mm
• Wall Thickness: 4.0 mm (reinforced structure)
• Standard Length: 25.2 meters/coil (25200 mm)
• Color Code: MBU (Medium Blue with stripe marking)
• Working Pressure: 0.8–1.2 MPa (116–174 PSI)
• Burst Pressure: ≥3.5 MPa (508 PSI)
• Temperature Range: -40℃ to +120℃ (short-term peak 150℃)
• Weight per Meter: 115g/m ±5%
• Total Coil Weight: 2.9 kg ±3%
• Coil Dimensions: 300mm (Dia) × 120mm (Width)
• Surface Finish: Smooth bore, low-friction interior
• Certifications: RoHS, REACH, FDA-compliant for incidental food contact

High-flex PA tubing engineered for precision pneumatic systems requiring chemical resistance and dimensional stability. Features anti-kink reinforcement and permanent color coding for easy circuit identification. The semi-transparent blue design allows visual flow monitoring.

Typical Applications:

• Robotic arm pneumatic gripper systems
• CNC machine tool coolant line protection sleeves
• Pharmaceutical blister packaging air lines
• Electric vehicle battery cooling system routing
• High-cycle automated assembly fixtures

Installation Guidelines: Maintain minimum bend radius of 60mm (2.4×OD). Use tube cutters for clean perpendicular ends. For pressurized connections above 0.5MPa, always employ matching PUSH-IN fittings with 15mm insertion depth. Avoid continuous exposure to chlorinated solvents.
