Airtac SULB Lock Cylinder SULB80X250
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB Series Locking Cylinder SULB80X250 Technical Details
- Model: SULB80X250
- Bore size: 80mm
- Stroke: 250mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: 2,500N (at 0.5MPa)
- Operation type: Double-acting with mechanical lock
- Lock activation: Pneumatic release (0.3–1.0MPa)
- Cushioning: Adjustable air cushion at both ends
- Port size: G1/2 (NPT1/2 optional)
- Rod type: Hard chrome-plated with anti-rotation guide
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Weight: 3.85kg (excluding accessories)
- Dimensions: 450mm(L) × 105mm(W) × 105mm(H) (fully extended)
- Mounting: ISO/VDMA standard front flange (MF1) and rear foot (FE)
- Protection rating: IP54 (standard), IP67 optional
Heavy-duty locking cylinder featuring fail-safe mechanical brake mechanism that engages automatically during power/pneumatic failure. The integrated non-rotating rod design ensures precise linear motion, while the dual-layer sealing system prevents leakage in high-vibration environments. Requires filtered air (5-40μm) with automatic lubrication (ISO VG32 recommended).
- Vertical lifting systems requiring position hold (elevator safety brakes)
- Automated welding fixtures needing vibration resistance
- Press machine tooling with emergency stop requirements
- Overhead material handling equipment
- Plastic injection molding clamp units
Installation criticals:
Maintain ≤0.5mm alignment tolerance during mounting. Always engage lock
before system pressurization during commissioning. Lubricate guide shafts
every 500km of cumulative travel.
Critical note:
Locking mechanism requires minimum 0.3MPa release pressure -
never exceed 1 cycle/sec frequency to prevent heat buildup.
| Property | Property Value |
|---|---|
| sku | SULB80X250 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | <250MM> → <250mm> |
| Lock Position | Rear Cover with Lock Type |
