Airtac X-UWS98A PU Flame-Resistant Straight Tube X-UWS98A060040050MBK
AirTAC X-UWS98A PU Flame-Retardant Straight Tube X-UWS98A060040050MBK Technical Details
- Full Model Code: X-UWS98A060040050MBK
- Material: Polyurethane (PU) with flame-retardant additives
- Color: Matte Black (MBK)
- Inner Diameter: 6.0mm ±0.2mm
- Outer Diameter: 10.0mm ±0.3mm
- Standard Length: 5 meters per coil
- Operating Temperature: -40℃ to +80℃ (short-term 120℃ for ≤1hr)
- Burst Pressure: ≥3.0 MPa
- Working Pressure: 0.8 MPa (recommended max)
- Bending Radius: ≥40mm (cold state)
- Elongation at Break: ≥250%
- Certification: UL 94 V-0 flammability rating
- Weight: 0.22 kg/m ±5%
- Coil Dimensions: 280mm(W) × 280mm(D) × 320mm(H)
- End Fittings Compatibility: Push-to-connect 6mm OD pneumatic connectors
- Surface Treatment: Anti-static coating
Industrial-grade polyurethane tubing with exceptional flame resistance and mechanical durability. Features a 3-layer construction: inner smooth bore for low friction loss, reinforcement braid for pressure retention, and UV-resistant outer layer. Maintains flexibility down to -40℃ with permanent anti-kink memory.
- Robotic welding station pneumatic lines
- Foundry equipment air supply systems
- CNC machine tool coolant-resistant air lines
- High-temperature automotive paint shop automation
- Plastics injection molding machine pneumatics
Installation guidelines:
Always deburr metal connectors before insertion. For high-vibration environments,
use tube clamps every 300mm. Minimum 1.5×OD clearance from heat sources.
Pressure test at 1.25× working pressure after installation.
- Excellent resistance to hydraulic oils (ISO VG32-68)
- Good resistance to diluted acids/alkalis (pH 4-10)
- Not recommended for ketones or concentrated oxidizing acids
| Property | Property Value |
|---|---|
| sku | X-UWS98A060040050MBK |
