Airtac 2WH High-Pressure Solenoid Valve 2WH030-06-A
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH030-06-A High Pressure Solenoid Valve Specifications
- Model: 2WH030-06-A
- Type: 2-position 3-way normally closed (pilot-operated)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.5–16 MPa (7–2320 PSI)
- Max pressure tolerance: Instantaneous 21 MPa, Continuous 16 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 500g ±3% (including coil)
- Dimensions: 85mm(L) × 55mm(W) × 90mm(H)
- Body material: Anodized aluminum alloy (AL6063-T5)
- Seal material: FKM fluorocarbon rubber
- Temperature range: -10℃ to 120℃ (non-freezing conditions)
- Power consumption: ≤2.5W (DC), ≤4.5VA (AC)
- Response time: ≤15ms (at 20℃, 1MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Flow coefficient (Cv): 2.3 (at 0.7MPa)
High-pressure optimized solenoid valve with reinforced internal structure for industrial hydraulic/pneumatic systems. Features pressure shock absorption chambers and anti-vibration design. The enlarged flow path achieves 30% higher flow rate than standard models at 10MPa. Requires 25μm filtered media (air/oil/gas) with ISO 8573-1:2010 Class 3 purity.
- Hydraulic press clutch/brake control systems
- CNC machine tool hydraulic units
- High-pressure pneumatic testing equipment
- Injection molding machine core-pulling mechanisms
- Compressed natural gas (CNG) control systems
Installation requirements:
Maximum allowable mounting angle: 15° from vertical axis.
Requires surge protection circuit for electrical connections.
Lubrication: ISO VG32 hydraulic oil recommended for sliding parts.
Critical note:
Not compatible with phosphate ester-based fluids.
Minimum 500-hour dry cycle testing required before high-pressure operation.
Ambient temperature must not exceed 50℃ when operating above 10MPa.
| Property | Property Value |
|---|---|
| sku | 2WH030-06-A |
| Port Size | PT1/6 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
