Airtac 2WH High-Pressure Solenoid Valve 2WH030-06-B
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH030-06-B High Pressure Solenoid Valve Specifications
- Model: 2WH030-06-B
- Type: 3-position (5-port) closed center, pilot-operated
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.5–16 MPa (72–2320 psi)
- Max pressure rating: 20 MPa (2900 psi) burst resistance
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 1.2 (at 7 bar)
- Response time: ≤25ms (actuation), ≤15ms (release)
- Weight: 680g ±5% (including coil)
- Dimensions: 94mm(L) × 45mm(W) × 86mm(H)
- Valve body material: Anodized aluminum alloy (A6063-T5)
- Seal material: Fluororubber (FKM) standard (NBR optional)
- Temperature range: -20℃ to 150℃ (with FKM seals)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Protection rating: IP67 (coil), IP65 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-pressure heavy-duty solenoid valve engineered for extreme pneumatic systems, featuring triple-position control and anti-vibration design. The hardened stainless steel spool and dual-chamber pilot structure ensure reliable operation under pulsating pressures. Compatible with compressed air, inert gases, and hydraulic oils (ISO VG32 or lighter).
- Hydraulic press clamping systems
- CNC machine tool coolant control
- High-pressure gas compressors (300+ PSI)
- Off-road vehicle pneumatic brakes
- Plastic injection molding machines
- Industrial boiler safety venting systems
Installation note:
Requires 10-15μm filtration (lubricated air recommended). Mount in vibration-damped position
with manifold torque ≤35N·m. Perform monthly manual override tests for critical systems.
Allow 30-second cooldown between rapid cycling operations.
