Airtac 2WH High-Pressure Solenoid Valve 2WH030-06-C
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH030-06-C High-Pressure Solenoid Valve Specifications
- Model: 2WH030-06-C
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: PT3/8 (G3/8 optional)
- Max operating pressure: 0.5–16 MPa (7–2320 PSI)
- Voltage options: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Weight: 450g ±5% (with coil)
- Dimensions: 85mm(L) × 50mm(W) × 70mm(H)
- Seal material: FKM fluorocarbon rubber (standard), optional EPDM
- Temperature range: -10℃ to 120℃ (medium/ambient)
- Power consumption: DC: 8W / AC: 6VA
- Response time: ≤15ms (at 20℃, 0.5MPa)
- Protection rating: IP65 (coil), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
- Max flow rate: 750 L/min (Cv=1.8 at 0.5MPa)
Heavy-duty high-pressure solenoid valve with reinforced stainless steel core and anti-vibration design. Features triple-layer sealing system for extreme pressure containment. Rated for continuous 100% duty cycle operation with ≤500,000 cycles MTBF. Requires 10μm filtration (25μm max) and lubrication-free air (ISO 8573-1 class 3).
- Hydraulic system pressure regulation in CNC machinery
- High-pressure water jet cutting systems (up to 1500 bar)
- Injection molding machine clamping units
- Pneumatic test bench pressure sequencing
- Oil & gas pipeline control systems
Installation criticals:
Mount horizontally with flow arrow alignment. Maintain 15mm clearance for heat dissipation.
Use anti-pulsation fittings when connecting to reciprocating pumps. Apply 24-48VAC surge
protection for AC coils in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | 2WH030-06-C |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC 110V |
