Airtac 2WH High-Pressure Solenoid Valve 2WH030-08-A
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH030-08-A High-Pressure Solenoid Valve Specifications
- Model: 2WH030-08-A
- Type: 5/3-way closed-center (pilot-operated)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure: 0.2–10 MPa (29–1450 PSI)
- Max pressure rating: 16 MPa (burst pressure 32 MPa)
- Voltage options: DC12V/24V, AC110V/220V (50/60Hz)
- Power consumption: 2.2W (DC), 4.5VA (AC)
- Flow coefficient (Cv): 2.5
- Response time: ≤15ms (at 5MPa)
- Seal material: Fluorocarbon rubber (FKM)
- Body material: Anodized aluminum alloy
- Temperature range: -10℃ to 150℃ (with FKM seals)
- Protection rating: IP67 (dust/water resistant)
- Weight: 480g ±5% (without connector)
- Dimensions: 98mm(L) × 52mm(W) × 83mm(H)
- Port thread depth: 12mm (minimum engagement)
Heavy-duty high-pressure solenoid valve engineered for industrial hydraulic/pneumatic systems requiring precise directional control under extreme pressures. Features triple-coil protection against voltage spikes and a dual-chamber design that prevents internal condensation. Compatible with ISO VG32 hydraulic oil and most non-corrosive gases. Requires 10μm filtration and periodic lubrication (every 5M cycles).
- Hydraulic press clutch/brake systems
- CNC machine tool coolant control
- High-pressure gas chromatography systems
- Off-road vehicle suspension controls
- Plastic injection molding machines
- Subsea equipment pneumatic controls
Installation note:
Mount with vibration-damping brackets in high-shock environments.
Maintain 15° maximum deviation from vertical orientation.
Pre-charge system to ≥3MPa before initial activation to prevent seal deformation.
| Property | Property Value |
|---|---|
| sku | 2WH030-08-A |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC220V |
