Airtac 2WH High-Pressure Solenoid Valve 2WH030-08-C
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH030-08-C High Pressure Solenoid Valve Technical Details
- Model Code: 2WH030-08-C
- Valve Type: 3-position, 5-way direct-acting (closed center)
- Port Thread: G1/8 (BSPP) with ISO standardized interface
- Operating Pressure Range: 0.3-16 MPa (43-2,320 PSI)
- Voltage Variants: DC12V/24V ±10%, AC110V/220V ±10% (50/60Hz)
- Flow Capacity: 1,200 NL/min (ANR) at 0.5MPa
- Response Time: ≤15ms (excitation), ≤20ms (de-excitation)
- Seal Materials: HNBR main seals with FKM backup rings
- Ambient Temp Range: -20℃ to +80℃ (non-freezing)
- Coil Insulation: Class F (155℃) with surge protection
- Electrical Connection: DIN43650 Form A connector
- Weight: 480g ±5% (including coil)
- Dimensions: 62mm(L) × 45mm(W) × 74mm(H) (body only)
- Mounting: Direct piping or sub-base optional
- Protection Class: IP67 (coil), IP40 (valve body)
Heavy-duty solenoid valve engineered for ultra-high pressure pneumatic systems, featuring tungsten carbide-coated spool for extreme wear resistance. The dual-pressure balanced design enables stable operation under pressure fluctuations. Includes manual override and position indicator. Requires ISO 8573-1 Class 3 lubricated air (32°F.R. value).
- Hydraulic-to-pneumatic booster systems
- CNC machine tool clamping mechanisms
- High-pressure tire inflation stations
- Plastic injection molding machines
- Test bench pressure regulation systems
Critical Note:
Install pressure relief valve downstream. Maximum allowable
instantaneous pressure spike: 20MPa. Lubricate every 2 million
cycles using ISO VG32 turbine oil. Avoid mounting in vibration
zones exceeding 50m/s².
| Property | Property Value |
|---|---|
| sku | 2WH030-08-C |
| Port Size | PT1/4 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC 110V |
