Airtac 2WH High-Pressure Solenoid Valve 2WH03006CI
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH03006CI High-Pressure Solenoid Valve Specifications
- Model: 2WH03006CI
- Type: 3-position, 5-way direct acting (double solenoid)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.2–25 MPa (290–3625 psi)
- Max working pressure: 31.5 MPa (4567 psi)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (±10%), AC220V (±10%)
- Coil insulation class: Class F (155℃)
- Weight: 1.2 kg ±5%
- Dimensions: 134mm(L) × 64mm(W) × 105mm(H)
- Body material: Anodized aluminum alloy (ISO 1A11)
- Seal material: Fluororubber (FKM) standard (NBR optional)
- Temperature range: -10℃ to 80℃ (with FKM seals)
- Response time: ≤20ms (at 20℃ nominal pressure)
- Flow rate: 1200 NL/min (ANR, at 0.5 MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Mounting orientation: Any (recommended vertical port orientation)
Heavy-duty high-pressure solenoid valve engineered for extreme pneumatic systems. Features triple-layer epoxy-coated coil for moisture resistance and reinforced stainless steel core tube. Includes manual override and position indicator. Compatible with ISO 5599/1 mounting interface for modular systems.
- Hydraulic-pneumatic hybrid press machines
- High-pressure gas compressor control systems
- CNC punching machine tool changers
- Offshore drilling equipment pneumatic controls
- Industrial boiler safety venting mechanisms
Installation requirements:
Requires minimum 50μm filtration. Lubricator recommended for
extending seal life. Allow 15-minute cool-down period after
continuous 8-hour high-pressure operation. Maintenance cycle:
500,000 actuations or 12 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | 2WH03006CI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC 110V |
