Airtac 2WH High-Pressure Solenoid Valve 2WH03006EI
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH High Pressure Solenoid Valve 2WH03006EI Specifications
- Model: 2WH03006EI
- Type: 2-position, 3-way normally closed (pilot-operated)
- Port size: G3/8 (BSPP thread)
- Operating pressure range: 0.5–12 MPa
- Max pressure: 15 MPa (burst pressure 30 MPa)
- Voltage options: DC24V (±10%), AC110V/220V (±15% 50/60Hz)
- Power consumption: 4.8W (DC24V), 5.5VA (AC)
- Response time: ≤15ms (actuation), ≤20ms (release)
- Flow coefficient (Cv): 1.6
- Seal material: HNBR (Hydrogenated Nitrile) with FKM backup rings
- Valve body material: Anodized aluminum alloy (A6063)
- Temperature range: -20℃ to 150℃ (medium), -5℃ to 80℃ (ambient)
- Protection rating: IP67 (connector included)
- Weight: 480g ±5%
- Dimensions: 78mm(L) × 54mm(W) × 65mm(H) (excluding connectors)
- Port thread depth: 12mm (G3/8)
- Manual override: Optional mechanical override button
Heavy-duty high-pressure solenoid valve engineered for extreme industrial environments. Features triple-seal construction with redundant pressure compensation, capable of handling viscous fluids and particulate-laden media (up to 40μm). The hardened stainless steel plunger and dual-coil design ensure reliable operation under continuous high-pressure cycling.
- Hydraulic pressurization systems in oil & gas equipment
- High-pressure water jet cutting machines
- CNC machine tool coolant control (emulsified oils)
- Diesel engine test bench fuel systems
- Mining equipment pneumatic controls
- High-altitude aviation ground support systems
Installation requirements:
Mount with vibration-damping brackets in high-shock environments.
Always install downstream 5μm filter and pressure relief valve.
For vertical mounting, orient coil upward to prevent debris accumulation.
Allow 15mm minimum clearance around valve body for heat dissipation.
| Property | Property Value |
|---|---|
| sku | 2WH03006EI |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | AC24V |
