Airtac 2WH High-Pressure Solenoid Valve 2WH03006F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Wide pressure range applicability - available in Ultra-high pressure (X), High pressure (H), Standard, Large flow (L), and Super-large flow (T) variants;
3、Compact structure with minimized dimensions, lightweight design, and tool-free installation;
4、Brass valve body construction with Class B thermal-rated coil. Standard FPMF (Fluoroelastomer Viton®) seals compatible with multiple media. Custom seal materials available upon request (consult technical department);
5、IP65-rated coil protection. Wiring options: Direct lead wire or DIN connector configuration.
Category: High Pressure Solenoid Valves | Brand: AIRTAC | Series: 2WH
AirTAC 2WH High Pressure Solenoid Valve 2WH03006F Technical Details
- Model: 2WH03006F (Industrial High Pressure Series)
- Valve type: 3-position, 5-way (double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.5–21 MPa (7–3,045 PSI)
- Voltage variants: DC24V (±10%), AC220V (±10% 50/60Hz)
- Max flow rate: 1,200 NL/min (ANR)
- Response time: ≤20ms (pressurized at 21MPa)
- Body material: Stainless steel SS304
- Seal material: HNBR with PTFE reinforcement
- Ambient temperature: -40℃ to 120℃ (with condensation prevention)
- Protection class: IP67 (dust/water resistant)
- Weight: 800g ±5% (without connectors)
- Dimensions: 100mm(L) × 50mm(W) × 60mm(H)
Heavy-duty high-pressure solenoid valve engineered for extreme industrial environments. Features triple-layer sealing architecture and electromagnetic shielding design. Requires 10μm filtration and automatic drain functionality for optimal performance. Compatible with ISO VG32 hydraulic oil and HFA/HFC fluids.
- Hydraulic press pressure regulation systems
- Offshore oil & gas blowout preventers
- High-pressure waterjet cutting machines (3,000+ PSI)
- Mining equipment pneumatic controls
- Plastic injection molding machine hydraulics
Installation protocol:
Must install vibration dampeners when used with pulsating systems.
Requires 15mm clearance on all sides for heat dissipation.
Lubricate sliding parts with ISO VG15 turbine oil monthly.
| Property | Property Value |
|---|---|
| sku | 2WH03006F |
| Port Size | PT1/8 |
| Flow Aperture | <2mm> |
| Coil Voltage | DC12V |
