Airtac ASQ Series Single Acting Slim Cylinder ASQ12X10
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ12X10 Single-Acting Compact Cylinder Specifications
- Model: ASQ12X10
- Type: Single-acting spring return (piston type)
- Bore size: 12mm
- Stroke: 10mm
- Operating pressure: 0.15–0.8 MPa
- Max theoretical thrust: 10.8N @0.5MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) with optional NPT1/8 adaptor
- Cushioning: Adjustable rubber buffer
- Seal material: NBR + polyurethane (rod seal)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel SUS304
- Mounting options: Basic type (no pre-mount holes) with optional MB12 bracket
- Weight: 58g ±2g
- Dimensions: 32mm(W) × 42mm(H) × 62mm(L) (stroke extended)
- Repeat positioning accuracy: ±0.5mm
- ISO standard: 6432 compliant (compact series)
Ultra-slim pneumatic cylinder optimized for space-constrained automation systems. Features anti-rotation rod design and dual-purpose mounting slots for flexible integration. The chrome-plated piston rod provides enhanced corrosion resistance in humid environments. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.3 air quality.
- PCB handling robots in electronics assembly
- Micro-dosing valves in pharmaceutical packaging
- Lens positioning mechanisms in optical equipment
- Precision clamping in watchmaking CNC fixtures
- Vending machine product ejection systems
Installation note:
For vertical mounting, ensure rod end faces downward to prevent debris accumulation.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃. Max lateral load: 2N.
- Magnetic sensor kit ASQ-M12A (non-contact reed switch)
- Rod-end adapter ASQ-E12 (M4 threaded tip)
- Heat-resistant variant available (up to 120℃)
| Property | Property Value |
|---|---|
| sku | ASQ12X10 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
