Airtac ASQ Series Single Acting Slim Cylinder ASQ12X5B
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ12X5B Single-Acting Compact Cylinder Specifications
- Model: ASQ12X5B
- Type: Single-acting (spring return)
- Bore size: 12mm
- Stroke: 5mm (standard) / customizable up to 50mm
- Operation: Push type (extends with air pressure)
- Working pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8
- Cushioning: Rubber buffer (adjustable end cushion optional)
- Mounting style: Basic type (no built-in mount)
- Material: Aluminum alloy barrel, POM end caps
- Piston rod material: Stainless steel (SUS304)
- Seal type: NBR seals
- Weight: 50g ±3%
- Dimensions:
- Length: 42mm (full retracted)
- Width: 16mm (body diameter)
- Height: 25mm (including mounting protrusions)
Ultra-slim pneumatic cylinder optimized for space-constrained automation systems. Features 50% reduced installation depth compared to standard cylinders, with precision-ground rod for smooth operation. Includes anti-rotation design for stable linear motion. Requires 0.1-1.0μm filtered air (ISO 8573-1 class 3).
- PCB handling robots
- Micro-dosing valves in medical devices
- Precision clamping in watchmaking
- Paper feed mechanisms in printers
- Lens positioning in optical equipment
Operation note:
Lubricate with ISO VG32 hydraulic oil (1 drop/month minimum).
Maximum side load: 0.5N. For vertical mounting,
use rod-down orientation to prevent condensation accumulation.
| Property | Property Value |
|---|---|
| sku | ASQ12X5B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
