Airtac ASQ Series Single Acting Slim Cylinder ASQ12X5SB
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ12X5SB Single-Acting Compact Cylinder Specifications
- Model: ASQ12X5SB
- Type: Single-acting spring return (piston type)
- Bore size: 12mm
- Stroke: 5mm (standard), customizable up to 50mm
- Operating pressure: 0.05-0.9 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Mounting style: Basic type (no built-in mounting)
- Cushioning: Fixed rubber bumper
- Seal material: NBR (nitrile) with graphite coating
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Weight: 0.045kg ±2%
- Dimensions:
- Length: 43mm (excluding rod)
- Width: 16mm (body diameter)
- Height: 16mm (body diameter)
- Stroke-specific total length: 43mm + stroke
- Air consumption: 0.57cm³/stroke @0.5MPa
- ISO standard: Compliant with ISO 6432
Ultra-slim pneumatic actuator designed for precision linear motion in confined spaces. Features dual-port design for flexible piping and maintenance-free operation. The hard-coat anodized surface provides exceptional wear resistance, while the stainless steel rod prevents corrosion in humid environments. Requires 5μm filtered air with ISO VG32 lubricator oil (optional).
- PCB handling robots in electronics manufacturing
- Micro-press mechanisms for medical device assembly
- Precision positioning in semiconductor wafer stages
- Valve actuation in compact analytical instruments
- Automated lens adjustment in optical systems
Installation guidelines:
Maintain ≤0.3mm alignment tolerance during mounting. Use swivel joints to prevent
side load. For vertical mounting, install with rod end downward to prevent
contaminants accumulation. Maximum lateral load: 0.8N.
| Property | Property Value |
|---|---|
| sku | ASQ12X5SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
