Airtac MSG Stainless Steel Mini Air Cylinder MSG20X100S
The AirTAC Airtac MSG Stainless Steel Mini Air Cylinder MSG20X100S is a genuine single acting, push (spring return) JIS-standard round-body mini air cylinder with a Ø20mm bore and 100mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ20 mm
- Stroke100 mm
- Port size1/8"
- Acting typeSingle acting, push (spring return)
- Rod threadM8×1.25
- CushionFixed anti-impact bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MSG Stainless Steel Mini Air Cylinder MSG20X100S
The AirTAC MSG20X100S is a single acting, push type JIS mini cylinder with a 20 mm bore and 100 mm stroke: compressed air extends the rod, and an internal return spring retracts it when air is released. Because air is only needed on the work stroke, one air line and one valve port are enough, which saves air and simplifies the circuit for one-way clamping, ejecting or pressing. The push force is already net of the spring: about 109.9 N at 0.5 MPa and 172.7 N at 0.7 MPa. As a rule of thumb, size the working load at about 0.6 of the push force, so roughly 65 N, or about 6 kgf for a safe vertical lift at 0.5 MPa.
Construction is a round-body JIS-standard mini cylinder with a riveted SUS304 stainless barrel and a hard-chrome plated carbon steel rod, so it resists damp and washdown environments. The two-way lubricant-storing piston seal reduces wear, and a fixed anti-impact bumper pad softens the stroke ends without acting as a lock or brake. The fitted magnet (the S in the code) allows CMSG, DMSG or EMSG switches to be mounted for end-position sensing. The port is 1/8" on every MSG bore, and the male rod thread is M8x1.25.
Airtac MSG Stainless Steel Mini Air Cylinder MSG20X100S Technical Specifications
| Model | Airtac MSG Stainless Steel Mini Air Cylinder MSG20X100S |
|---|---|
| Series | MSG JIS mini cylinder |
| Bore size | Ø20 mm |
| Stroke | 100 mm |
| Acting type | Single acting, push (spring return) |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 150 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø20mm)
| Pressure | Push force (spring return) |
|---|---|
| 0.5 MPa | 109.9 N |
| 0.7 MPa | 172.7 N |
Single-acting push: air extends the rod; the return spring retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac MSG Stainless Steel Mini Air Cylinder MSG20X100S
| MSG | JIS round-body mini cylinder (single-acting push, spring-return). |
|---|---|
| 20 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MSG Stainless Steel Mini Air Cylinder MSG20X100S Is Used
Spring-return clamping
Air pushes the 8 mm rod out to clamp a small fixture or workpiece; on air release the spring retracts the rod automatically, freeing the part with no return valve needed.
Part ejection
With about 109.9 N push at 0.5 MPa, the cylinder ejects finished small parts off a chute or nest at the end of a cycle, and the spring resets it for the next part.
Light lid press
The 172.7 N push at 0.7 MPa suits light press-fit and lid-closing jobs on small assemblies; the fixed bumper pad softens the end of the 100 mm stroke.
Is the Airtac MSG Stainless Steel Mini Air Cylinder MSG20X100S the Right Cylinder?
Choose the MSG20X100S when a 20 mm bore gives enough force: about 109.9 N push at 0.5 MPa or 172.7 N at 0.7 MPa, net of the return spring. It is the smallest bore in the MSG range; step up to MSG25, MSG32 or MSG40 if you need more push. Remember the spring sets a 0.2 MPa (28 psi) minimum working pressure, and the spring-return travel caps standard strokes at 150 mm, so 100 mm is within range. If you need a two-directional stroke or a longer travel, choose the double-acting MG instead. Mounting options are LB foot, FA flange, CB clevis and SDB pivot, plus I and Y rod knuckles; this S-coded model carries a magnet for CMSG/DMSG/EMSG switches. Thread is PT; G and NPT are available on request.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MSG Stainless Steel Mini Air Cylinder MSG20X100S FAQ
The net push (already after the return spring) is 109.9 N at 0.5 MPa and 172.7 N at 0.7 MPa. Operating pressure is 0.2-1.0 MPa (28-145 psi) with a 1.5 MPa (215 psi) proof pressure, air filtered to 40 um, temperature -20 to +70 C, and speed 50-800 mm/s. The port is 1/8" and the male rod thread is M8x1.25.
This is a single acting push cylinder: air extends the rod and the internal spring retracts it when air is released, so only one air line and one valve port are needed. On air loss the spring returns the rod to rest; it does not hold a load, and the bumper pad is not a brake. The fitted magnet allows CMSG, DMSG or EMSG switches. For a two-way stroke, use the double-acting MG.
