Airtac MTG Stainless Steel Mini Cylinder MTG25X50
1. Compliant with JIS standards for precision engineering;
2. Features an asymmetric bidirectional sealing structure on the piston, delivering compact dimensions and integrated oil reservoir functionality to optimize lubrication retention;
3. Equipped with fixed cushion pads on both end caps, effectively mitigating directional change impacts and prolonging service life;
4. End caps and stainless steel barrel are secured via crimped roller wrapping technology, ensuring robust structural integrity;
5. High-precision stainless steel tubing construction provides exceptional strength and superior corrosion resistance;
6. Versatile mounting accessories available for flexible installation configurations.
Category: Mini Cylinders | Brand: Airtac | Series: MTG
AirTAC MTG Stainless Steel Miniature Cylinder MTG25X50 Specifications
- Model: MTG25X50
- Type: Single-acting spring return (push type)
- Bore size: 25mm
- Stroke: 50mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -20℃ to 150℃
- Cushioning: Adjustable elastic buffer
- Port thread: M5×0.8 (standard) / NPT1/8 optional
- Rod end thread: M6×1.0
- Material: Stainless steel (SUS304 main body)
- Seal material: Heat-resistant NBR + Fluororubber (FKM) composite
- Weight: 0.62kg (excluding accessories)
- Dimensions: 118mm(L) × 25mm(Bore) × 32mm(Mounting height)
- Protection rating: IP67 (standard wiper design)
- Max theoretical thrust: 441N @0.7MPa
- Piston speed: 50–700mm/s
Precision-engineered stainless steel cylinder with corrosion-resistant construction, featuring dual-material seals for high/low temperature stability. The compact profile enables direct mounting in confined spaces while maintaining ISO 6432 compliance. Requires 5μm filtered dry air and recommends using ISO VG32 hydraulic oil mist lubrication.
- Cleanroom automation in semiconductor manufacturing
- Food processing machinery (FDA-compliant version available)
- Pharmaceutical tablet press ejection systems
- High-cycle textile machinery actuators
- Marine environment pneumatic controls
Installation note:
Maintain ≤0.1mm alignment tolerance during mounting. For vertical installations,
use rod-down orientation to prevent condensate accumulation. Apply 0.5-1Nm torque
on mounting screws with thread-locking compound.
| Property | Property Value |
|---|---|
| sku | MTG25X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <25 mm> |
| Stroke | <50mm> |
