Airtac MTG Stainless Steel Mini Cylinder MTG25X50S
The AirTAC Airtac MTG Stainless Steel Mini Cylinder MTG25X50S is a genuine single acting, pull (spring return) JIS-standard round-body mini air cylinder with a Ø25mm bore and 50mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ25 mm
- Stroke50 mm
- Port size1/8"
- Acting typeSingle acting, pull (spring return)
- Rod threadM10×1.25
- CushionFixed anti-impact bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MTG Stainless Steel Mini Cylinder MTG25X50S
The AirTAC MTG25X50S is a single acting, pull-type JIS round-body mini cylinder with a 25 mm bore and 50 mm stroke: an internal spring holds the rod out at rest, and compressed air retracts (pulls) it on the work stroke. Because air acts on only one side, a single 1/8" port feeds the whole cycle, which simplifies plumbing on draw, retract, close and tension motions. Net pull output, already after the spring, is about 132.6 N at 0.5 MPa and 215 N at 0.7 MPa, with working pressure from 0.2 MPa (28-145 psi range) and speed from 50 to 800 mm/s. The fitted magnet (the S code) allows CMSG, DMSG or EMSG switches to signal rod position.
Construction suits damp and washdown-adjacent lines: a SUS304 stainless barrel, a hard-chrome plated carbon-steel rod (20 um chrome), riveted covers and a two-way lubricant-storing piston seal, with a fixed anti-impact bumper pad softening each stroke end. In practical terms, 132.6 N is roughly 13.5 kgf, so halving it gives a safe working load of about 6 kg for vertical lifting duty. The spring return also defines fail-safe behaviour: on air loss the rod extends back out, so the cylinder will not hold a load in the retracted position. Strokes above the 150 mm standard limit, or two-way travel, call for the double-acting MG instead.
Airtac MTG Stainless Steel Mini Cylinder MTG25X50S Technical Specifications
| Model | Airtac MTG Stainless Steel Mini Cylinder MTG25X50S |
|---|---|
| Series | MTG JIS mini cylinder |
| Bore size | Ø25 mm |
| Stroke | 50 mm |
| Acting type | Single acting, pull (spring return) |
| Port size | 1/8" |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 150 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø25mm)
| Pressure | Pull force (spring return) |
|---|---|
| 0.5 MPa | 132.6 N |
| 0.7 MPa | 215.0 N |
Single-acting pull: the spring extends the rod; air retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac MTG Stainless Steel Mini Cylinder MTG25X50S
| MTG | JIS round-body mini cylinder (single-acting pull, spring-return). |
|---|---|
| 25 | Bore size in mm. |
| ×50 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MTG Stainless Steel Mini Cylinder MTG25X50S Is Used
Retract a locking pin
Air pulls the pin out of a fixture or die on command; if air is lost, the spring pushes the pin back to its extended, engaged position for a fail-safe default.
Draw a web or tape
With about 132.6 N of pull at 0.5 MPa, the cylinder tensions and draws light webs, labels or tape in packaging lines, with the magnet and a CMSG switch confirming each pull stroke.
Close a shutter or gate
One air line closes a small slide or shutter on a machine guard; the spring reopens it automatically on air loss, and the fixed bumper pad softens both stroke ends.
Is the Airtac MTG Stainless Steel Mini Cylinder MTG25X50S the Right Cylinder?
Choose the MTG25X50S when your motion is a one-way pull of about 80 N or less at working pressure (132.6 N rated pull at 0.5 MPa, 215 N at 0.7 MPa, both net of the spring). Step down to bore 20 for lighter draws, or up to bore 32 or 40 when you need 225-550 N of pull; for two-way travel or strokes beyond 150 mm, use the double-acting MG. Remember the spring extends the rod and air retracts it, and the 0.2 MPa minimum working pressure must be available to overcome the spring. The S code means the magnet is fitted, so CMSG, DMSG or EMSG switches can be added. Mount with LB foot, FA flange, CB clevis or SDB pivot brackets, and I or Y rod knuckles; thread is PT (G and NPT available). Port is 1/8" on every MTG bore.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MTG Stainless Steel Mini Cylinder MTG25X50S FAQ
Net pull (already after the spring) is 132.6 N at 0.5 MPa and 215 N at 0.7 MPa for this 25 mm bore. Operating pressure is 0.2-1.0 MPa (28-145 psi) with a 1.5 MPa (215 psi) proof pressure, fluid is air filtered to 40 um, temperature range -20 to +70 C, and speed 50-800 mm/s. The port is 1/8" on every MTG bore, and the maximum standard stroke for bore 25 is 150 mm.
In the MTG the spring extends the rod and air retracts (pulls) it, so one 1/8" line runs the whole cycle and the rod fails to its extended position on air loss; the fixed bumper pad only softens stroke ends and does not lock a load. The MSG is the opposite single acting type (air pushes, spring retracts), and the MG is double acting, driven both ways by air for two-way travel and longer strokes. The S code on this model fits a magnet for CMSG, DMSG or EMSG switches.
