Airtac MTG Stainless Steel Mini Cylinder MTG25X75
The AirTAC Airtac MTG Stainless Steel Mini Cylinder MTG25X75 is a genuine single acting, pull (spring return) JIS-standard round-body mini air cylinder with a Ø25mm bore and 75mm stroke, 1/8" air ports and a SUS304 stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ25 mm
- Stroke75 mm
- Port size1/8"
- Acting typeSingle acting, pull (spring return)
- Rod threadM10×1.25
- CushionFixed anti-impact bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MTG Stainless Steel Mini Cylinder MTG25X75
The AirTAC MTG25X75 is a single acting, pull-type JIS mini cylinder with a 25 mm bore and 75 mm stroke: an internal spring holds the rod extended at rest, and compressed air retracts (pulls) the rod on the work stroke. Because air is only applied on the pull stroke, one air line and one valve position are all you need, which simplifies plumbing on draw, retract, close and tension motions. Net pull output, already after the spring, is about 132.6 N at 0.5 MPa and 215 N at 0.7 MPa; a realistic working figure is roughly 80 N, which will lift a vertical load of about 6 kg with margin.
The round-body barrel is SUS304 stainless with a hard-chrome plated 10 mm rod (male thread M10x1.25), riveted covers and a fixed anti-impact bumper pad that softens the stroke ends without acting as a lock or brake. Ports are 1/8" on every MTG bore, operating pressure is 0.2-1.0 MPa (28-145 psi) with a 1.5 MPa (215 psi) proof rating, speed range 50-800 mm/s and temperature -20 to +70 C. The spring-return design caps the standard stroke at 150 mm for this bore; for longer travel or powered two-way motion step up to the double-acting MG series.
Airtac MTG Stainless Steel Mini Cylinder MTG25X75 Technical Specifications
| Model | Airtac MTG Stainless Steel Mini Cylinder MTG25X75 |
|---|---|
| Series | MTG JIS mini cylinder |
| Bore size | Ø25 mm |
| Stroke | 75 mm |
| Acting type | Single acting, pull (spring return) |
| Port size | 1/8" |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 150 mm |
Specifications follow the official AirTAC MG-series (JIS standard) datasheet. Barrel: SUS304 stainless steel (round-body, riveted construction); piston rod: carbon steel with 20µm hard-chrome plating. Thread options: PT (blank) / G / NPT.
Theoretical Output Force (Ø25mm)
| Pressure | Pull force (spring return) |
|---|---|
| 0.5 MPa | 132.6 N |
| 0.7 MPa | 215.0 N |
Single-acting pull: the spring extends the rod; air retracts it. Forces already net the spring; minimum working pressure is 0.2 MPa.
Model Code: Airtac MTG Stainless Steel Mini Cylinder MTG25X75
| MTG | JIS round-body mini cylinder (single-acting pull, spring-return). |
|---|---|
| 25 | Bore size in mm. |
| ×75 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
| FA / LB / CB / SDB | Mounting: FA flange, LB foot, CB clevis, SDB pivot bracket (with CB). |
MG-family variants: MG / MGC (double acting ±cushion), MSG / MTG (single acting push / pull), MGD / MGCD (double rod ±cushion). Accessories: LB foot, FA flange, CB clevis, SDB pivot block, plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MTG Stainless Steel Mini Cylinder MTG25X75 Is Used
Retract a locating pin
Air pulls the pin out of a fixture nest on demand, and the spring pushes it back into position the moment pressure drops, giving a fail-safe extended state with a single 1/8" air line.
Tension a light belt or web
With about 80 N of practical working pull, the MTG25X75 keeps a conveyor belt or film web under steady spring-applied tension while air pressure adjusts the take-up point.
Close a small shutter or gate
Draw a chute gate or hopper shutter closed on the work stroke; on air loss the spring reopens it automatically, so jammed product cannot leave the line blocked.
Is the Airtac MTG Stainless Steel Mini Cylinder MTG25X75 the Right Cylinder?
Size the MTG25X75 by pull force, not bore alone: at 0.5 MPa it delivers 132.6 N net of the spring, about 215 N at 0.7 MPa. If your load needs more, move up to MTG32 (224.8 N at 0.5 MPa) or MTG40 (339.1 N); if less, MTG20 (84.8 N) is the smallest in the family. Remember the spring extends the rod and air retracts it, so the supply must overcome the spring from 0.2 MPa (28 psi) upward. The 75 mm stroke is within the 150 mm standard limit for bore 25; longer strokes or two-way travel call for the double-acting MG. Mount with LB foot, FA flange, CB clevis or SDB pivot, add I or Y rod knuckles as needed, and order the -S code if you want a CMSG, DMSG or EMSG switch, since the magnet is optional. Thread is PT as standard, with G and NPT variants.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting (LB / FA / CB / SDB) & knuckle
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check On first run, back off the cushion/impact settings and release gradually.
- check Installation by qualified personnel per AirTAC docs.
Airtac MTG Stainless Steel Mini Cylinder MTG25X75 FAQ
Net pull, already after the spring, is 132.6 N at 0.5 MPa and 215 N at 0.7 MPa. Operating pressure is 0.2-1.0 MPa (28-145 psi), proof pressure is 1.5 MPa (215 psi), speed range is 50-800 mm/s, and the temperature range is -20 to +70 C with air filtered to 40 um. The port is 1/8" and the rod is 10 mm with an M10x1.25 male thread.
In the MTG the spring extends the rod and air retracts (pulls) it, so on air loss the rod returns to its extended rest position. The MSG is the opposite single acting type: air pushes and the spring retracts. The MG is double acting, with air on both sides for powered two-way travel and strokes beyond the 150 mm spring-return limit. If you need position sensing, order the -S option to fit a CMSG, DMSG or EMSG switch, since the magnet is not fitted otherwise.
