Airtac 2JS Angle Seat Valve 2JS150-10-Q40
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JS150-10-Q40 Angle Seat Valve Specifications
- Model: 2JS150-10-Q40
- Type: 2-way normally open (manual reset)
- Flow path design: Right-angle configuration
- Port size: G1/2" (ISO228/1 standard)
- Effective flow diameter: 10mm
- Operating pressure: 0.1–1.0 MPa
- Max working temperature: 180℃ (with PTFE seal)
- Body material: CF8M stainless steel (AISI 316 equivalent)
- Seal options: PTFE (standard), EPDM (high-temp variant)
- Actuation force: ≤50N @ 0.6MPa
- Weight: 0.68kg ±2%
- Dimensions: 118mm(L) × 76mm(W) × 132mm(H)
- Surface finish: 0.8μm Ra (fluid contact areas)
- Certifications: RoHS compliant, REACH registered
Heavy-duty angle seat valve featuring zero dead volume design for precise fluid control in aggressive media applications. The 316 stainless steel construction and vacuum-brazed seals enable operation with steam, mild acids, and alkaline solutions. Unique cam-lever mechanism allows 90° manual override even under full system pressure.
- Sterilization systems in pharmaceutical CIP/SIP processes
- High-temperature condensate drainage in steam lines
- Chemical dosing systems with corrosive liquids
- Beverage filling line shut-off with viscous fluids
- Vacuum chamber pressure regulation
Installation protocol:
Always install with actuator lever facing accessible position. Apply PTFE tape
on male threads using clockwise wrapping. Perform 50 open/close cycles at 0.3MPa
before full-pressure operation to seat seals properly.
| Property | Property Value |
|---|---|
| sku | 2JS150-10-Q40 |
| Port Size | G3/8 |
| Flow Aperture | <15mm> |
