Airtac 2JS Angle Seat Valve 2JS150-10-Q50
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JS150-10-Q50 Angle Seat Valve Specifications
- Model: 2JS150-10-Q50
- Type: 2/2-way normally closed (pneumatic actuation)
- Port size: G1/2 (ISO228/1 standard)
- Operating pressure: 0.2–10 bar (3–145 psi)
- Voltage options: 24VDC, 110VAC, 220VAC (solenoid version)
- Weight: 1.2 kg (with actuator)
- Dimensions: 150mm(L) × 80mm(W) × 120mm(H)
- Body material: Stainless steel CF8M (316 equivalent)
- Seal material: PTFE + FKM (high-temp variant available)
- Temperature range: -20℃ to 150℃ (standard seals)
- Flow coefficient: Cv 4.2 (Kv 3.6)
- Response time: ≤0.3s (at 6 bar)
- Protection rating: IP67 (solenoid version)
- Media compatibility: Air, water, steam, mild chemicals
Heavy-duty angle seat valve with 90° flow path optimization, featuring a stainless steel body and fail-safe spring return mechanism. The piston-driven design ensures bubble-tight shut-off with ≤0.1 bar differential pressure. Enhanced PTFE stem seals enable steam compatibility up to 8 bar saturated steam.
- High-temperature liquid filling systems
- Steam sterilization equipment in pharma
- Beverage industry CIP (Clean-in-Place) systems
- Chemical dosing pumps with aggressive media
- Autoclave pressure control systems
Installation guidelines:
Mount with actuator positioned horizontally to prevent condensate accumulation.
Use 5μm filtration for pneumatic supply. Replace seals every 500,000 cycles
in continuous operation (consult manual for media-specific schedules).
| Property | Property Value |
|---|---|
| sku | 2JS150-10-Q50 |
| Port Size | G3/8 |
| Flow Aperture | <15mm> |
