Airtac 2JS Angle Seat Valve 2JS150-15-Q40
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JS150-15-Q40 Angle Seat Valve Technical Details
- Model: 2JS150-15-Q40
- Type: 2-way normally open (pneumatic actuation)
- Port connection: G1/2" ISO228 standard
- Flow coefficient (Cv): 0.6
- Operating pressure: 0.1–1.0 MPa
- Max media temperature: 180℃ (dry air/oil-free)
- Ambient temperature range: -10℃ to 60℃
- Valve body material: Stainless steel CF8M (SS316 equivalent)
- Seal material: PTFE + EPDM composite
- Actuation pressure: 0.3–0.8 MPa compressed air
- Response time: ≤0.3s (open/close cycle)
- Weight: 0.92 kg ±5%
- Dimensions: 152mm(L) × 48mm(W) × 98mm(H)
- Protection class: IP67 (dust/water resistant)
- Certifications: RoHS compliant, ISO 5211 mounting standard
Heavy-duty angle pattern valve with thermal-shock resistant design, featuring zero dead volume for precise flow control in high-temperature steam and aggressive media applications. The 45° seat design prevents particle accumulation and enables bubble-tight shutoff. Requires 5μm filtered compressed air for actuator operation.
- Steam sterilization systems in pharmaceutical manufacturing
- High-temperature CIP (Clean-in-Place) processes
- Chemical dosing systems with corrosive liquids
- Beverage filling line steam tracing control
- Textile machinery steam conditioning
Installation guidelines:
Mount with flow direction matching body arrow marking. For viscous media,
orient actuator vertically upward. Perform monthly seal lubrication using
silicone-free grease (ISO VG 32 equivalent). Avoid water hammer by installing
shock absorber when closing against >0.6 MPa pressure.
| Property | Property Value |
|---|---|
| sku | 2JS150-15-Q40 |
| Port Size | G1/2 |
| Flow Aperture | <15mm> |
