Airtac 2JS Angle Seat Valve 2JS15015Q50G
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JS15015Q50G Angle Seat Valve Specifications
- Model: 2JS15015Q50G
- Type: 2/2-way normally closed (spring return)
- Port size: G1/2" (ISO228/1 standard)
- Connection type: BSPP threaded
- Operating pressure: 0.15–1.0 MPa
- Max working pressure: 10 bar
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 5.5W (AC), 6.5W (DC)
- Flow coefficient (Cv): 4.0
- Response time: ≤50ms (open/close)
- Seal material: PTFE + EPDM (FDA compliant)
- Body material: Stainless steel CF8M (AISI 316)
- Temperature range: -10℃ to 180℃ (with high-temp seals optional)
- Protection rating: IP67 (NEMA 4X equivalent)
- Weight: 650g ±5%
- Dimensions: 120mm(L) × 50mm(W) × 80mm(H)
- Actuation: Pneumatic pilot operated
- Media compatibility: Compressed air, water, steam (≤180℃), mild chemicals
- Certifications: RoHS, REACH, ISO 9001:2015
High-flow angle seat valve with 45° port configuration for optimized fluid dynamics. Features steam-resistant construction with electropolished internals, designed for aggressive media and high-cycle applications. The stainless steel body provides exceptional corrosion resistance in food/pharmaceutical environments. Requires 5μm filtered media.
- Steam sterilization systems in biotech facilities
- High-temperature CIP (Clean-in-Place) processes
- Beverage filling line volumetric control
- Chemical dosing systems with aggressive fluids
- Textile machinery steam injection
Installation guidelines:
Mount with actuator facing upward for condensate drainage.
Use PTFE thread sealant (not tape) for steam applications.
Allow 15-minute cool-down period after steam exposure before servicing.
| Property | Property Value |
|---|---|
| sku | 2JS15015Q50G |
| Port Size | G1/2 |
| Flow Aperture | <15mm> |
