Airtac 2JS Angle Seat Valve 2JS15015Q50T
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JS15015Q50T Angled Seat Valve Specifications
- Model: 2JS15015Q50T
- Type: 2-way normally closed (pneumatic actuation)
- Port size: G1/2 (ISO228/1 standard)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC24V (±10%) / AC220V (±10%)
- Flow coefficient (Cv): 4.2
- Response time: ≤0.1s (actuation)
- Weight: 1.8 kg (with solenoid)
- Dimensions: 160mm(L) × 105mm(W) × 135mm(H)
- Seal material: FKM (Viton®) for high temp resistance
- Temperature range: -10℃ to 150℃ (medium) / -5℃ to 80℃ (ambient)
- Protection rating: IP67 (solenoid part)
- Housing material: Stainless steel SS304 (body) + anodized aluminum (actuator)
- Port connection: Internal thread ISO1179 (EN10226)
Heavy-duty angled seat valve with 90° flow path design, optimized for high-temperature liquid/gas control. Features stainless steel construction with V-shaped PTFE stem seal for zero-leakage performance. Includes manual override and position indicator. Requires 50μm filtered air supply (0.4-0.6 MPa recommended for optimal actuation).
- Steam line isolation in food processing equipment
- High-pressure cleaning machine fluid control
- Chemical dosing systems with aggressive media
- Beverage filling line shut-off applications
- Pharmaceutical CIP/SIP processes
Installation note:
Mount with flow direction arrow aligned. Allow 20mm clearance below actuator for maintenance.
Use thread sealant (PTFE tape prohibited) on NPT versions. Cycle rate ≤5Hz.
| Property | Property Value |
|---|---|
| sku | 2JS15015Q50T |
| Port Size | G1/2 |
| Flow Aperture | <15mm> |
