Airtac 2JS Angle Seat Valve 2JS200-20-Q50
$153.76
Regular price
$161.26
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
2JS200-20-Q50
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Pneumatic-controlled operation enables safe deployment in explosive environments and non-electrical applications. Features low actuation pressure requirements for reliable low-pressure control over high-pressure systems.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
Installation note:
Mount with actuator facing upward. Allow 50mm clearance for stem maintenance.
Always install downstream filter regulator. Cycle life exceeds 1,000,000 operations
when used within specified pressure range.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JS200-20-Q50 Angle Seat Valve Specifications
- Model: 2JS200-20-Q50
- Type: 2-way normally open (manual reset)
- Port size: G3/4" (ISO228/1 standard)
- Thread type: Female BSPP
- Operating pressure: 0.2–1.0 MPa
- Max working pressure: 10 bar
- Temperature range: -10℃ to 180℃
- Fluid viscosity: ≤600 cSt
- Valve body material: CF8M stainless steel (AISI 316)
- Seal material: PTFE + EPDM
- Actuation: Pneumatic (air pilot required)
- Response time: ≤0.3s
- Flow coefficient (Cv): 6.3
- Weight: 2.8 kg ±5%
- Dimensions: 165mm(L) × 105mm(W) × 208mm(H)
- Protection rating: IP67
- Certification: RoHS compliant
High-temperature angle seat valve with 90° flow path design for steam and aggressive media control. Features zero-leakage piston seal technology and anti-vibration stem design. Requires 4-7 bar pilot pressure with filtered (<25μm) dry air supply. Optional position indicator available.
Typical Applications:
- Steam sterilization systems in pharmaceutical production
- High-pressure CIP (Clean-in-Place) systems
- Thermal oil circulation control
- Beverage filling line steam injection
- Chemical dosing systems with corrosive media
Installation note:
Mount with actuator facing upward. Allow 50mm clearance for stem maintenance.
Always install downstream filter regulator. Cycle life exceeds 1,000,000 operations
when used within specified pressure range.
| Property | Property Value |
|---|---|
| sku | 2JS200-20-Q50 |
| Port Size | G3/4 |
| Flow Aperture | <20mm> |
