Airtac 2JS Angle Seat Valve 2JS200-20-Q63
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JS200-20-Q63 Angle Seat Valve Specifications
- Model: 2JS200-20-Q63
- Type: 2/2-way normally closed (pneumatic actuation)
- Port size: G3/4 (ISO228/1 standard)
- Operating pressure: 0.15–1.0 MPa
- Voltage options: DC24V, AC110V, AC220V (solenoid version)
- Weight: 2.8 kg ±3%
- Dimensions: 200mm(L) × 120mm(W) × 160mm(H)
- Flow coefficient (Cv): 20.0
- Seal material: PTFE/Viton (standard), EPDM optional
- Temperature range: -5℃ to 180℃ (with high-temp seals)
- Response time: ≤0.3s (at 0.6 MPa)
- Protection rating: IP67 (solenoid version)
- Body material: Stainless steel CF8M (316 equivalent)
- Actuation: Pneumatic piston with spring return
- Media compatibility: Air, water, steam, mild chemicals
Heavy-duty angle seat valve featuring 45° flow path design for low pressure drop and bubble-tight shutoff. The stainless steel construction with PTFE/Viton sealing ensures chemical resistance and thermal stability. Optional manual override allows emergency operation during power failures. Requires 5μm filtered air supply for actuator.
- High-temperature liquid dispensing systems
- Steam sterilization equipment in pharmaceutical plants
- CIP (Clean-in-Place) systems for food processing
- Industrial boiler feed water control
- Chemical dosing systems with aggressive media
Installation note:
Mount with flow direction arrow aligned. For steam applications,
install with valve stem angled downward (15° minimum) to prevent
condensate accumulation. Lubricate seals every 2,000 operating cycles.
| Property | Property Value |
|---|---|
| sku | 2JS200-20-Q63 |
| Port Size | G3/4 |
| Flow Aperture | <20mm> |
