Airtac 2JS Angle Seat Valve 2JS25025Q80T
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JS25025Q80T Angle Seat Valve Specifications
- Model: 2JS25025Q80T
- Type: 2/2-way normally closed (pneumatic actuation)
- Port size: G1" (BSPP thread)
- Operating pressure: 0.15–1.0 MPa
- Max working pressure: 1.6 MPa
- Voltage options: DC24V/AC220V (solenoid coil)
- Actuation pressure: 0.3–0.8 MPa (pneumatic)
- Seal material: PTFE + EPDM (high-temp variant available)
- Temperature range: -10℃ to 180℃ (standard seals)
- Flow coefficient (Cv): 25
- Response time: ≤0.3s (at 0.6 MPa)
- Weight: 850g ±5%
- Dimensions: 120mm(L) × 52mm(W) × 72mm(H)
- Protection rating: IP67 (solenoid version)
- Media compatibility: Water, steam, neutral gases, mild chemicals
Heavy-duty angle seat valve with 304 stainless steel body and precision-machined piston system. Features zero-leakage design with spring-assisted closure and manual override capability. The 90° flow path reduces pressure drop, optimized for high-cycle applications requiring rapid shut-off. Requires 5μm filtered air supply for actuator.
- Liquid filling systems in beverage production
- Steam control in sterilization equipment
- High-temperature water circulation systems
- Chemical dosing pumps in water treatment
- Clean-in-Place (CIP) systems in pharma
Installation note:
Mount with flow direction arrow aligned. For steam applications,
install with valve stem angled downward (15° minimum) to prevent
condensate accumulation. Lubricate piston every 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | 2JS25025Q80T |
| Port Size | G1 |
| Flow Aperture | <25 mm> |
