Airtac 2JS Angle Seat Valve 2JS320-32-Q80
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JS320-32-Q80 Angle Seat Valve Specifications
- Model: 2JS320-32-Q80
- Type: 2-position 5-way (spring return)
- Port size: G1/2 (ISO228/1 standard)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Valve body material: Stainless steel CF8M
- Seal material: FKM (Fluoro Rubber) standard (NBR optional)
- Temperature range: -20℃ to 150℃ (medium/ambient)
- Flow capacity: Cv=3.2 (Kv=2.75)
- Response time: ≤50ms (at 0.5MPa)
- Weight: 1.85kg ±2%
- Dimensions: 150mm(L) × 82mm(W) × 105mm(H)
- Protection rating: IP67 (coil), IP65 (valve body)
- Mounting orientation: Any (360° rotatable piping ports)
High-flow angle seat valve with stainless steel construction and thermal shock resistance. Features bubble-tight shut-off (Class IV leakage) and 5 million cycle durability. The 45° seat design prevents media stagnation, with optional steam-cleaning compatibility (130℃/266℉ max). Requires 5μm filtered air supply (lubricated or non-lubricated).
- High-temperature steam line control
- Chemical dosing systems with aggressive media
- Beverage filling line shut-off valves
- Pharmaceutical CIP/SIP processes
- Hydraulic oil cooling circuits
Installation note:
For viscous media (>50cSt), install with actuator facing downward.
Always perform stroke adjustment via the manual override before
commissioning. Minimum 10mm vibration damping required in
pulsation systems.
| Property | Property Value |
|---|---|
| sku | 2JS320-32-Q80 |
| Port Size | G1-1/4 |
| Flow Aperture | <32 mm> |
