Airtac 2JS Angle Seat Valve 2JSK15010Q40G
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JSK15010Q40G Angle Seat Valve Specifications
- Model: 2JSK15010Q40G
- Type: 2-position 5-way, single solenoid with spring return
- Port size: G1/2 (NPT1/2 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 1,800 l/min (Cv=2.0 at 7 bar)
- Weight: 1.2 kg (with coil)
- Dimensions: 120mm(L) × 65mm(W) × 85mm(H)
- Body material: Stainless steel CF8M (316 equivalent)
- Seal material: NBR/FKM (optional PTFE for chemical resistance)
- Temperature range: -20℃ to 80℃ (NBR seals) / -10℃ to 150℃ (FKM seals)
- Response time: ≤25ms (at rated voltage)
- Protection rating: IP67 (coil), IP65 (valve body)
- Port connection: ISO 228/1 standard threads
- Manual override: Built-in emergency operation button
High-flow angle seat valve with 90° fluid path design for efficient directional control. Features stainless steel construction with electropolished internals for reduced particle generation. The optimized pilot structure ensures reliable operation under low pressure (down to 0.15MPa). Includes LED status indicator and surge protection circuit.
- Steam control in food processing equipment
- Chemical dosing systems with aggressive media
- High-cycle packaging line actuators (200+ cycles/min)
- Water treatment plant pneumatic systems
- Pharmaceutical CIP/SIP processes
Installation note:
Mount in any orientation except inverted. Use pulsation dampeners when controlling
high-viscosity fluids (>500cSt). Replace seals every 5 million cycles or 12 months
in continuous operation. Requires 5μm filtered air supply for pilot operation.
| Property | Property Value |
|---|---|
| sku | 2JSK15010Q40G |
| Port Size | G3/8 |
| Flow Aperture | <15mm> |
