Airtac 2JS Angle Seat Valve 2JSK15010Q50G
$132.57
Regular price
$140.07
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
2JSK15010Q50G
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Pneumatic-controlled operation enables safe deployment in explosive environments and non-electrical applications. Features low actuation pressure requirements for reliable low-pressure control over high-pressure systems.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
Installation guidelines:
Mount with actuator facing upward (vertical installation preferred).
Use PTFE thread sealant on connections. Allow 30mm clearance around
actuator for heat dissipation. Flush valve body before first use
with actual medium at 50% pressure.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JSK15010Q50G Angle Seat Valve Specifications
- Model: 2JSK15010Q50G
- Type: 2-way normally closed (spring return)
- Port connection: G1/2" ISO228 standard
- Valve orifice: 15mm (DN15 equivalent)
- Operating pressure: 0-10 bar (1.0 MPa)
- Maximum pressure: 16 bar
- Voltage options: AC24V/110V/220V ±10% 50/60Hz
- Power consumption: 5.5VA (AC)
- Weight: 0.82 kg ±3%
- Dimensions: 150mm(L) × 85mm(W) × 112mm(H)
- Body material: CF8M stainless steel (AISI 316)
- Seal material: PTFE + EPDM composite
- Temperature range: -10℃ to 180℃ (medium)/ -5℃ to 80℃ (ambient)
- Flow coefficient (Cv): 4.2
- Response time: ≤0.1s
- Protection rating: IP67 (coil)/ IP65 (valve body)
- Certifications: RoHS, CE, ISO 9001
High-temperature angle seat valve with 316 stainless steel construction, designed for aggressive media control. Features zero-leakage PTFE diaphragm and thermal isolation design between actuator and fluid path. Requires 15-20% duty cycle for continuous operation above 120℃.
Typical Applications:
- Steam control in food processing autoclaves
- Chemical dosing systems with corrosive liquids
- High-temperature water circulation in breweries
- Pharmaceutical CIP/SIP processes
- Textile dyeing machine pressure regulation
Installation guidelines:
Mount with actuator facing upward (vertical installation preferred).
Use PTFE thread sealant on connections. Allow 30mm clearance around
actuator for heat dissipation. Flush valve body before first use
with actual medium at 50% pressure.
| Property | Property Value |
|---|---|
| sku | 2JSK15010Q50G |
| Port Size | G3/8 |
| Flow Aperture | <15mm> |
