Airtac 2JS Angle Seat Valve 2JSK15015Q40G
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JSK15015Q40G Angle Seat Valve Specifications
- Model: 2JSK15015Q40G
- Type: 2-way normally closed (pneumatic actuation)
- Port size: G1/2" (ISO228/1 standard)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Actuation pressure: ≥0.3 MPa
- Voltage options: 24VDC, 110VAC, 220VAC (solenoid version)
- Weight: 850g ±5% (without accessories)
- Dimensions: 150mm(L) × 78mm(W) × 115mm(H)
- Body material: Stainless steel CF8M (316 equivalent)
- Seal material: PTFE + EPDM (high-temperature variant available)
- Temperature range: -10℃ to 180℃ (standard seals), up to 200℃ with special seals
- Flow coefficient (Cv): 4.2 (Kv=3.6)
- Response time: ≤0.3s (at 0.6 MPa)
- Protection rating: IP67 (solenoid coil)
- Mounting orientation: Vertical stem position recommended (±15° tolerance)
Heavy-duty angle seat valve with 90° flow path optimization, featuring a stainless steel body for corrosive environments. The spring-assisted closure mechanism ensures fail-safe operation during pressure drops. Includes a visual position indicator and manual override. Compatible with steam, compressed air, and mildly aggressive media (pH 5-9). Requires 5μm filtration for optimal seat longevity.
- Steam sterilization systems in pharmaceutical production
- High-temperature fluid control in food processing lines
- Chemical dosing systems with aggressive media
- Industrial boiler feed water control
- Clean-in-Place (CIP) systems with rapid cycling requirements
Installation note:
Install with flow direction arrow aligned. For steam applications,
allow 10-minute warm-up period with valve partially open to prevent
thermal shock. Lubricate piston assembly every 5,000 cycles using
PAG-based grease (ISO VG 32 equivalent).
| Property | Property Value |
|---|---|
| sku | 2JSK15015Q40G |
| Port Size | G1/2 |
| Flow Aperture | <15mm> |
