Airtac 2JS Angle Seat Valve 2JSK25025Q50G
$183.75
Regular price
$191.25
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
2JSK25025Q50G
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Pneumatic-controlled operation enables safe deployment in explosive environments and non-electrical applications. Features low actuation pressure requirements for reliable low-pressure control over high-pressure systems.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
Installation notes:
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JSK25025Q50G Angle Seat Valve Specifications
- Model: 2JSK25025Q50G
- Type: 2/2-way normally closed (spring return)
- Port size: G2" (DN50) with ISO 228/1 thread
- Operating pressure: 0.2–1.0 MPa
- Voltage options: AC24V/DC24V/AC110V/AC220V (customizable)
- Medium temperature: -10℃ to +180℃
- Body material: Stainless steel CF8M (316 equivalent)
- Seal material: FKM fluorocarbon rubber
- Flow coefficient (Cv): 45
- Response time: ≤0.3s (actuation to full open)
- Protection rating: IP67 (coil)/IP65 (valve body)
- Weight: 1.85 kg (without coil), 2.3 kg (with coil)
- Dimensions: 212mm(L) × 125mm(W) × 168mm(H)
High-flow angle seat valve with 90° stainless steel body design, optimized for steam/hot water applications. Features thermal isolation between actuator and fluid path, with explosion-proof coil options available. Requires 25μm filtration for optimal performance.
Typical Applications:
- Steam sterilization systems in pharmaceutical plants
- High-temperature CIP (Clean-in-Place) processes
- Beverage filling line hot water control
- Industrial boiler feedwater systems
- Thermal oil circulation control
Installation notes:
- Arrow marking must align with medium flow direction
- Allow 15mm clearance for actuator movement
- Use PTFE thread sealant (not tape) for steam applications
- Perform quarterly lubrication of stem guide
Special Functions:
- Manual override via integrated emergency lever
- Double-sealed stem design prevents external leakage
- Anti-water-hammer optimized flow path
- ESD-protected coil connections
| Property | Property Value |
|---|---|
| sku | 2JSK25025Q50G |
| Port Size | G1 |
| Flow Aperture | <25 mm> |
