Airtac 2JS Angle Seat Valve 2JSK32032Q63G
$251.21
Regular price
$258.71
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
2JSK32032Q63G
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Pneumatic-controlled operation enables safe deployment in explosive environments and non-electrical applications. Features low actuation pressure requirements for reliable low-pressure control over high-pressure systems.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
Installation guidelines:
Install with flow direction arrow aligned. For steam applications,
allow 15-minute warm-up period before full pressure operation.
Lubricate stem annually with silicone-free grease (P/N: AG-8).
Critical note:
Not suitable for particulate-laden media without upstream filtration.
Minimum 100μm filter recommended. Avoid water hammer by installing
speed controllers when used with quick-exhaust valves.
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JSK32032Q63G Angle Seat Valve Technical Specifications
- Model: 2JSK32032Q63G
- Type: 2-way normally open (spring return)
- Operation: Pneumatic actuation with manual override
- Port size: G1" (BSPP thread)
- Flow coefficient (Cv): 4.0
- Pressure range: 0.15–10 bar (operating), 12 bar max
- Temperature range: -10℃ to 180℃ (with FKM seals)
- Seal material options:
- Standard: FKM (Fluorocarbon)
- Optional: EPDM (-20℃~140℃), PTFE (0℃~200℃)
- Voltage variants:
- Pneumatic: 4-7 bar control pressure
- Optional solenoid versions: 24VDC, 110VAC, 220VAC
- Body material: Stainless steel CF8M (316 equivalent)
- Weight: 2.85 kg (with standard fittings)
- Dimensions: 120mm(L) × 65mm(W) × 75mm(H)
- Response time: ≤0.3s (at 6 bar)
- Protection rating: IP67 (solenoid version)
- Certifications: RoHS, REACH, ISO 228-1
Heavy-duty angle seat valve designed for high-temperature and corrosive media applications. Features 316 stainless steel construction with precision-machined piston guide system for leak-free operation. The 45° seat design enables bubble-tight shutoff even with viscous fluids. Compatible with steam, compressed air, and mild chemicals.
Typical Applications:
- Steam line control in food processing plants
- Chemical dosing systems in water treatment
- High-temperature oil circulation in plastic injection molding
- Beverage filling line shut-off control
- Pharmaceutical CIP/SIP processes
Installation guidelines:
Install with flow direction arrow aligned. For steam applications,
allow 15-minute warm-up period before full pressure operation.
Lubricate stem annually with silicone-free grease (P/N: AG-8).
Critical note:
Not suitable for particulate-laden media without upstream filtration.
Minimum 100μm filter recommended. Avoid water hammer by installing
speed controllers when used with quick-exhaust valves.
| Property | Property Value |
|---|---|
| sku | 2JSK32032Q63G |
| Port Size | G1-1/4 |
| Flow Aperture | <32 mm> |
