Airtac 2JS Angle Seat Valve 2JSK32032Q80G
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JSK32032Q80G Angle Seat Valve Specifications
- Model: 2JSK32032Q80G
- Type: 2/2-way normally closed (pneumatic actuation)
- Port connection: G1/2 (ISO228/1 standard)
- Actuation: Pneumatic pilot control (air-to-open)
- Operating pressure range: 0.1–1.0 MPa
- Max working pressure: 16 bar (232 psi)
- Fluid temperature range: -10℃ to +180℃
- Seal material: PTFE + Kalrez® (high-temp variant)
- Body material: Stainless steel CF8M (316 equivalent)
- Flow coefficient (Cv): 4.2
- Response time: ≤0.3s (at 6 bar)
- Weight: 520g ±5% (without accessories)
- Dimensions: 120mm(L) × 80mm(W) × 110mm(H)
- Protection rating: IP67 (dust/water resistant)
- Certification: RoHS compliant, ISO 5211 mounting interface
Heavy-duty angle seat valve optimized for steam and aggressive media control, featuring zero-leakage sealing through spring-assisted piston closure. The 45° flow path design minimizes pressure drop while enabling efficient drainage. Includes integrated position indicator window for visual status confirmation.
- Steam sterilization systems in pharmaceutical production
- High-temperature CIP (Clean-in-Place) fluid control
- Beverage filling line shut-off with viscous liquids
- Chemical dosing systems with corrosive media
- Textile machinery steam conditioning
Installation guidelines:
Mount with flow direction arrow aligned. For steam applications,
install condensate separator upstream. Manual override available
via 6mm hex key (clockwise for emergency closure).
Minimum 200μm filtration recommended.
| Property | Property Value |
|---|---|
| sku | 2JSK32032Q80G |
| Port Size | G1-1/4 |
| Flow Aperture | <32 mm> |
