Airtac 2JS Angle Seat Valve 2JSY15010Q40G
2. Stainless steel construction (body & linkage) ensures superior corrosion resistance. PTFE sealing components provide broad chemical compatibility, suitable for high-temperature and highly corrosive fluid handling.
3. Optimized 45° angle seat design with streamlined internal flow path minimizes pressure drop and ensures laminar flow for enhanced throughput. Integrated filter element in linkage prevents contamination ingress, extending service life.
4. Position indicator window enables visual monitoring and precise flow rate adjustment. Optional retrofit with limit switch or emergency manual override for enhanced functionality.
5. Recessed metal pneumatic ports with transition adaptor plate facilitate seamless installation of NAMUR-standard solenoid valves.
6. 360° rotatable actuator assembly simplifies orientation adjustment during installation.
Category: Angle Seat Valve | Brand: AIRTAC | Series: 2JS
AirTAC 2JSY15010Q40G Angle Seat Valve Technical Details
- Model: 2JSY15010Q40G
- Type: 2-way normally open (pneumatic actuation)
- Port connection: G1/2" ISO228 standard
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC24V (±10%) / AC220V (50/60Hz)
- Weight: 680g ±5% (including solenoid)
- Dimensions: 132mm(L) × 55mm(W) × 105mm(H)
- Body material: Stainless steel SS304
- Seal material: PTFE + EPDM composite
- Temperature range: -10℃ to 180℃ (steam compatible)
- Flow coefficient (Cv): 4.2 (at 6 bar)
- Response time: ≤0.3s (actuation to full open/close)
- Protection rating: IP67 (splash-proof coil)
- Media compatibility: Air, water, neutral gases, mild chemicals
Heavy-duty angle seat valve with 90° flow path design, optimized for high-temperature liquid/steam applications. Features zero-leakage piston seal technology and anti-vibration coil design. Includes manual override function for emergency operation. Requires 5-7 bar control air pressure for optimal performance.
- Steam sterilization systems in pharmaceutical plants
- Hot water circulation control in food processing
- Chemical dosing systems with aggressive media
- Textile machinery steam injection control
- Industrial dishwasher water inlet systems
Installation guidelines:
Mount with flow arrow aligned to media direction. For vertical installation,
position actuator upward. Use PTFE thread sealant on connections.
Include a 10μm filter in pneumatic line. Annual seal inspection recommended.
| Property | Property Value |
|---|---|
| sku | 2JSY15010Q40G |
| Port Size | G3/8 |
| Flow Aperture | <15mm> |
