Airtac 2JW Angle Seat Valve 2JW15010Q40G
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JW15010Q40G Angle Seat Valve Specifications
- Model: 2JW15010Q40G
- Type: 2-way normally open (spring return)
- Port size: G1/2" (ISO228/1 standard)
- Thread connection: Rc1/2 (PT1/2 optional)
- Operating pressure: 0.15–1.0 MPa
- Max working pressure: 1.6 MPa
- Voltage options: DC24V (±10%), AC110V/220V (±15%)
- Power consumption: 5.5W (DC24V), 7VA (AC)
- Weight: 980g ±2% (with coil)
- Dimensions: 132mm(L) × 78mm(W) × 105mm(H)
- Seal material: PTFE + FKM (high temp variant available)
- Temperature range: -10℃ to 180℃ (standard seals)
- Response time: ≤15ms (at 0.5MPa)
- Flow coefficient (Cv): 4.2
- Protection rating: IP67 (coil), IP65 (valve body)
- Media compatibility: Air, water, steam (max 80% dryness)
Heavy-duty angle seat valve with 304 stainless steel body and thermal isolation design. Features a 45° flow path for reduced pressure drop and bubble-tight shut-off. The piston-driven mechanism enables zero-leakage performance even after 5 million cycles. Includes manual override and position indicator. Requires 5μm filtered media with viscosity <21 cSt.
- Steam sterilization systems in pharmaceutical plants
- High-temperature CIP (Clean-in-Place) processes
- Beverage filling line shut-off control
- Industrial boiler condensate drainage
- Thermal oil circulation systems
Installation note:
Mount with actuator facing upward. Allow 20mm clearance for heat dissipation in steam applications.
Use spiral-wound gaskets (SWG) for pipe connections exceeding 120℃.
| Property | Property Value |
|---|---|
| sku | 2JW15010Q40G |
| Port Size | G3/8 |
| Flow Aperture | <15mm> |
