Airtac 2JW Angle Seat Valve 2JW15015Q40G
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JW15015Q40G Angle Seat Valve Specifications
- Model: 2JW15015Q40G
- Type: 2-way normally closed (spring return)
- Port size: G1/2 (ISO228/1 standard)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow coefficient (Cv): 4.2 (at 7 bar)
- Max media temperature: 150℃ (302℉) with FKM seals
- Ambient temperature: -10℃ to 60℃
- Response time: ≤50ms (actuation), ≤80ms (reset)
- Body material: Stainless steel CF8M (SS316 equivalent)
- Seal materials: FKM/Viton (standard), EPDM optional
- Weight: 0.8kg (1.76 lbs)
- Dimensions: 150mm(L) × 85mm(W) × 65mm(H)
- Protection rating: IP67 (dust/water resistant)
- Electrical connection: DIN43650 Form A connector
High-flow angle seat valve with stainless steel construction and thermal shock resistance. Features manual override button for system debugging and emergency shut-off. Designed for aggressive media including steam, hot water, and mild chemicals. Requires 50μm filtration and regular lubrication (every 500,000 cycles).
- Steam sterilization systems in pharmaceutical plants
- High-temperature liquid filling machines
- Industrial dishwasher water control
- Chemical dosing systems with corrosive fluids
- Textile dyeing equipment pressure regulation
Installation note:
Mount with actuator facing upward for optimal diaphragm life.
Use PTFE tape on threads and torque to 35-40 N·m.
Allow 5-minute cool-down period after steam applications.
| Property | Property Value |
|---|---|
| sku | 2JW15015Q40G |
| Port Size | G1/2 |
| Flow Aperture | <15mm> |
