Airtac 2JW Angle Seat Valve 2JW20020Q50G
$127.91
Regular price
$135.41
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
2JW20020Q50G
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Pneumatically controlled operation enables usage in electricity-free, flammable or explosion-prone environments. Features low actuation pressure capability with low-pressure control for high-pressure systems.
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
Installation requirements:
Must be mounted with actuator facing upward (±15° tolerance).
Apply thread sealant only on male threads (not compatible with PTFE tape).
Allow 5-minute cooling period after steam applications before servicing.
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JW20020Q50G Angle Seat Valve Specifications
- Model: 2JW20020Q50G
- Type: 2-position, 3-way normally closed (spring return)
- Port size: G1/2 (EN ISO 228-1 standard)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: AC24V (±10%), AC110V (±10%), AC220V (±10%)
- Weight: 980g ±2% (including coil)
- Dimensions: 112mm(L) × 75mm(W) × 108mm(H)
- Seal material: PTFE/Viton composite (FDA compliant)
- Temperature range: -10℃ to 180℃ (media temperature)
- Flow coefficient: Cv 3.2 (Kv 2.75)
- Response time: ≤25ms (at 0.6MPa)
- Protection rating: IP67 (coil protection)
- Housing material: CF8M stainless steel (AISI 316 equivalent)
High-temperature angle seat valve with zero leakage design, featuring a 45° flow path for reduced turbulence. The stainless steel construction and PTFE/Viton seals enable steam/hot water handling (up to 180℃). Includes manual override and position indicator. Requires 5μm filtered media with viscosity ≤21 cSt.
Industrial Applications:
- Sterilization equipment steam control
- Beverage filling line CIP systems
- Pharmaceutical process heating jackets
- Textile dyeing machine pressure regulation
- Chemical dosing systems with aggressive media
Installation requirements:
Must be mounted with actuator facing upward (±15° tolerance).
Apply thread sealant only on male threads (not compatible with PTFE tape).
Allow 5-minute cooling period after steam applications before servicing.
Maintenance Protocol:
- Lubricate piston assembly every 500,000 cycles using PAG-based grease
- Replace seat seal every 2 years or 10 million cycles (whichever comes first)
- Verify coil resistance quarterly (nominal 85Ω ±15% at 20℃)
| Property | Property Value |
|---|---|
| sku | 2JW20020Q50G |
| Port Size | G3/4 |
| Flow Aperture | <20mm> |
