Airtac 2JW Angle Seat Valve 2JW20020Q63G
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JW20020Q63G Angle Seat Valve Specifications
- Model: 2JW20020Q63G
- Type: 2-way normally open (pneumatic actuation)
- Port connection: G1/2" (ISO228/1 standard)
- Thread type: External thread (male)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max working pressure: 1.0 MPa
- Voltage options: AC24V (±10%), AC220V (±10%), DC24V (±10%)
- Weight: 580g ±5% (including solenoid coil)
- Dimensions: 102mm(L) × 52mm(W) × 76mm(H)
- Body material: Stainless steel CF8M (SS316 equivalent)
- Seal material: PTFE + EPDM composite
- Temperature range: -5℃ to 150℃ (medium temp.) / -10℃ to 60℃ (ambient)
- Flow coefficient (Cv): 2.3
- Response time: ≤0.15s (open/close cycle)
- Protection rating: IP67 (coil), IP65 (valve body)
- Mounting orientation: Vertical ±5° (recommended)
High-flow angle seat valve with 90° flow path design, featuring stainless steel construction for aggressive media handling. The PTFE/EPDM sealing system enables steam compatibility up to 150℃ intermittent use. Includes manual override and position indicator. Requires 5μm filtered compressed air (ISO 8573-1:2010 class 4.4.2).
- High-temperature liquid dispensing in food processing
- Steam line control for sterilization systems
- Corrosive chemical transfer in electroplating lines
- High-cycle packaging machine actuators (up to 1M cycles)
- Pharmaceutical CIP/SIP processes
Installation protocol:
Install with flow arrow alignment. Use PTFE tape on male threads.
For steam applications, preheat valve gradually (15min warm-up).
Maintain 20mm clearance below actuator for maintenance access.
| Property | Property Value |
|---|---|
| sku | 2JW20020Q63G |
| Port Size | G3/4 |
| Flow Aperture | <20mm> |
