Airtac 2JW Angle Seat Valve 2JW32032Q80G
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JW32032Q80G Angle Seat Valve Specifications
- Model: 2JW32032Q80G
- Type: 5/2-way pneumatic operated angle seat valve
- Port size: G1/2" (BSPP thread)
- Operating pressure: 0.15–1.0 MPa
- Voltage options: DC24V (±10%), AC110V/220V (±15% 50/60Hz)
- Weight: 2.3 kg (with accessories)
- Dimensions: 160mm(L) × 105mm(W) × 145mm(H)
- Body material: Stainless steel CF8M (SS316 equivalent)
- Seal material: PTFE+Viton composite
- Temperature range: -10℃ to 180℃ (medium temperature)
- Flow coefficient (Cv): 4.2
- Response time: ≤50ms (at 0.5MPa)
- Protection rating: IP67 (coil)/IP65 (valve body)
- Port alignment: 45° angled flow path design
- Actuation type: Pilot-operated with manual override
High-temperature resistant angle seat valve featuring zero dead volume design for precise fluid control in harsh environments. The 316 stainless steel construction and multi-layered sealing system ensure exceptional corrosion resistance against steam and aggressive media. Includes thermal isolation collar to protect solenoid components.
- Steam line control in food processing equipment
- Chemical dosing systems with corrosive liquids
- High-temperature water circulation in sterilizers
- Vacuum/pressure switching in semiconductor manufacturing
- Hydraulic oil control in molding machines
Installation note:
Mount with actuator facing upward for optimal drainage. Use 2x M5 mounting screws (not included).
For steam applications, install downstream strainer and maintain 15mm clearance below valve for condensate drainage.
Lubricate seals annually with silicone-free grease.
| Property | Property Value |
|---|---|
| sku | 2JW32032Q80G |
| Port Size | G1-1/4 |
| Flow Aperture | <32 mm> |
